iBASE ASTUT-1811S-PC Panel PC
iBASE ASTUT-1811S-PC Panel PC is built around a rugged design tailored for industrial environments such as manufacturing and logistics. It features an 18.5-inch TFT-LCD with projected capacitive touch for intuitive control, a robust black aluminium front bezel, and steel back cover with aluminium heat sink supporting fanless, continuous operation. Powered by an energy-efficient Intel Atom D2550 dual-core processor, it operates reliably across a temperature range from -20°C to 60°C, making it suited for varied field conditions. Dual Gigabit LAN ports ensure network connectivity is maintained in demanding setups, while a PCI expansion slot allows adaptation to specific application requirements.
The panel PC meets CE and RoHS standards, offers humidity resistance from 10 to 90% non-condensing, and withstands shock and vibration thanks to its sealed construction. Supporting Windows Embedded Standard 7 and Windows 7 Pro for Embedded, the system prioritises durability and adaptability for sustained industrial use.
ASTUT-1811S-PC Features
- Fanless Enclosure
- Capacitive Touch Screen
- High Performance & Reliable
- Wide-Range 12V~24V DC Power Input
- IP65 Waterproof Front Panel Protection
Request a Quote
Product Type
Manufacturer
Ruggedness
IP Rating
Mounting Format
Processor
Operating System
Country Of Manufacture
Taiwan
Certifications
CE, RoHS compliant
Custom Options Products
Interface,Processor,Memory,Storage,Connections,Operating System
Dimensions
520 x 341 x 84.4
Humidity
10-90% Humidity Resistant (non-condensing)
Operating System
Windows
Operating Temperature
0C~ 50C(with SSD/CFast)/ 0C~ 40C (with HDD)
Ordering Info
ASTUT-1811S-PC 18.5" Flat Panel Design Panel PC, Intel Atom D2550 1.86GHz, DDR3 SO-DIMM 4GB, with 320G HDD, projected capacitive touch, w/o adaptor Power adaptor AC 90~240V input, 12V DC output 84W power adaptor IBASE P/N: A005PS084W0050000P
Audio
1x MIC in/ Line out phone jack
Backlight Lifetime(hrs)
50000
Construction
Black aluminum front bezel and black steel back cover with aluminum heat-sink
Contrast
41.667361111111
Digital I/O
1x 6 pins terminal block 2in/2out/5VCC/Ground
Display Interface
1x VGA
Display Type
18.5" TFT-LCD
Expansion Slot
1x PCI
HDD
1x 2.5" SATA2
Interface
USB
Keyboard/Mouse
None
LAN
2x Gigabit LAN (RJ45)
Light Transmission (%)
85
Luminance (cd/m2)
300
Max. Color
16.7M
Max. Resolution
1366 x 768
Membrane Control
None
Memory
2x DDR3 1066 SO-DIMM, up to 4GB
Mounting
Panel Mount, VESA 75 x 75mm / 100 x 100mm
Mounting Type Filter
VESA, Panel Mount
Onboard Expansion Bus
1x Mini PCI-E half/full size
Operating System Support
Windows Embedded Standard 7, Windows 7 Pro for Embedded
Power
1x 3pin DC power connector
Power Input
12~36V DC input
Processor, Chipset
Intel Atom Processor D2550 (1M Cache, 1.8GHz)
Removable Slot
1x external CFast
Serial/Parallel
COM1/2 RS-232/422/485 isolated COM3 RS-232
Touch Type
Projected capacitive
Touch Type Filter
Capacitive
USB
4x USB 2.0
View Angle (H/V)
170ï¾°/160ï¾°
Processor
Intel
Storage Temperature
-20C~60C
The iBASE ASTUT-1811S-PC Panel PC is designed and engineered for use in demanding environments where reliability, durability are essential. The ASTUT-1811S-PC supports a wide range of industries and operational applications.
Common deployment industries include: Construction, Energy and Utilities, Industrial Manufacturing, Logistics And Supply Chain, Rail And Transport.
Across these sectors, the ASTUT-1811S-PC is typically used in applications such as Field Data Capture And Reporting, Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Inventory Management And Stock Control, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, Quality Control And Inspection, SCADA And Control-Room Access.
These examples demonstrate the versatility of the ASTUT-1811S-PC across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the ASTUT-1811S-PC is appropriate for your specific application, please contact us.
The iBASE ASTUT-1811S-PC Panel PC comes with a Standard Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE ASTUT-1811S-PC Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE ASTUT-1811S-PC Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the iBASE ASTUT-1811S-PC Panel PC, or would you like to discuss a customised solution?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iBASE ASTUT-1811S-PC or need a custom Rugged Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
