Digi TX64 5G / LTE-Advanced Pro Cellular Router

  • 5G
  • LTE
  • WIFI 6
  • GPS
  • ETHERNET
  • USB
  • MULTIPLE VPN

The Digi TX64 is a high-performance 5G and 4G LTE-Advanced Pro cellular router engineered for complex transit and transportation systems where many onboard applications must share resilient, secure connectivity. Powered by a quad-core processor with 2 GB of RAM and 8 GB of flash, it delivers true enterprise-class routing, security, firewall and integrated VPN, with dual redundant cellular communications that let operators run segmented data streams, such as separating signalling or payment traffic from passenger internet.

Its flexible interface design suits demanding mobile environments. Integrated Wi-Fi 6 provides a 4×4 MIMO 5 GHz radio for high-throughput backhaul alongside a 2×2 dual-band radio for passenger access, while a four-port Gigabit Ethernet switch, three USB 3.0 ports, an RS-232 serial interface and configurable options including dead-reckoning GNSS and Bluetooth connect the wider vehicle network. FirstNet Trusted and Verizon Frontline support make it suitable for emergency communications, and the router meets the U.S. government FIPS 140-3 standard with the Digi TrustFence security framework, a stateful firewall and IP filtering.

The TX64 is built to endure transport conditions, housed in an aluminium-alloy enclosure rated to IP40 and operating from -30°C to 70°C on a 9 to 36 VDC supply. It is centrally managed through Digi Remote Manager as part of the Digi 360 solution, with web UI, CLI and SNMP options, and supports value-added services such as Digi WAN Bonding and Digi Mobile VPN. This makes it a dependable communications hub for buses, light rail, transit fleets and other complex mobile deployments.

TX64-A161 Features

  • 5G and 4G LTE-Advanced Pro with a quad-core processor for enterprise-class routing
  • Dual redundant cellular communications for segmented data streams
  • Wi-Fi 6 with 4x4 MIMO backhaul plus a 2x2 dual-band passenger access radio
  • Four-port Gigabit Ethernet switch, three USB 3.0 ports, serial and dead-reckoning GNSS
  • FirstNet Trusted and Verizon Frontline support for emergency communications
  • FIPS 140-3 with Digi TrustFence, stateful firewall and IP filtering
  • Centrally managed via Digi Remote Manager (Digi 360) with web UI, CLI and SNMP

Request a Quote

Product Type

Manufacturer

Certifications & Standards

Ruggedness

IP Rating

Interface

Country Of Manufacture

United States

Cellular

5G NR Sub-6 GHz, 4G LTE-Advanced Pro, 3G fallback

Processor

Quad-core

Memory

2 GB RAM / 8 GB Flash

Wi-Fi

Wi-Fi 6 (802.11ax); 5 GHz 4x4 MIMO backhaul; 2.4/5 GHz 2x2 MIMO public access

GNSS

GPS, Galileo, BeiDou, GLONASS with Untethered Dead Reckoning

Ethernet

(4) RJ-45, 10/100/1000 Mbps

Serial

(1) RS-232, DB-9

USB

(3) USB 3.0 Type A

Bluetooth

Optional Bluetooth (configurable)

Power

9 to 36 VDC, 60 W minimum power source required

Operating Temperature

-30°C to 70°C

Enclosure

Aluminium alloy, IP40

Dimensions

260 mm x 196 mm x 67 mm (10.2 in x 7.8 in x 2.6 in)

Weight

3.3 kg (7.25 lb)

Security

FIPS 140-3, Digi TrustFence, stateful firewall, IP filtering, custom firewall rules

Approvals / Certifications

FIPS 140-3, PTCRB, UL 60950, CE, FCC Part 15

Management

Digi Remote Manager (cloud), web UI, CLI, SNMP

Warranty

3 years (Digi 360)

The Digi TX64 5G / LTE-Advanced Pro Cellular Router is designed and engineered for use in demanding environments where reliability, durability are essential. The TX64-A161 supports a wide range of industries and operational applications.

Common deployment industries include: Emergency Services, Logistics And Supply Chain, Public Sector, Rail And Transport, Security And Surveillance.

Across these sectors, the TX64-A161 is typically used in applications such as Emergency Dispatch And Incident Management, Fleet Management And Telematics, Mobile Workforce Operations, Remote Management, Route Planning And Navigation, Security And Surveillance Operations.

These examples demonstrate the versatility of the TX64-A161 across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the TX64-A161 is appropriate for your specific application, please contact us.

The Digi TX64 5G / LTE-Advanced Pro Cellular Router comes with a 3 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, Digi TX64 5G / LTE-Advanced Pro Cellular Router, must be presented to RUGGED in the United Kingdom.

For more information about the Digi TX64 5G / LTE-Advanced Pro Cellular Router or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
