DT-5K USB DT-5K PS2 DT-5K IP66-RATED DT-5K FORCE-SENSING-RESISTOR DT-5K DUSTPROOF DT-5K CUSTOMISABLE DT-5K CUSTOMISABLE


iKey-DT-2000-TB-Keyboard

DT-2000-TB iKey Keyboard

iKey-DT-5K-IS-Keyboard

DT-5K-IS iKey Keyboard

DT-5K iKey Keyboard

The DT-5K combines a Force Sensing Resistor, an upgraded pointing device that offers improved sensitivity and increased durability, with a 10-key numeric keypad in a ruggedized stainless steel case, providing dual functionality in one compact unit.

DT-5K Features

  • Highly-Rugged Stainless Steel Case
  • 113-Key Functionality / 10-Key Numeric Pad
  • Integrated Force Sensing Resistor
  • USB, PS2 and AT/Serial Configurations Available
  • Various Keyboard and Language Layout Options

Manufacturer: iKey

Availabilty: Est. 5 - 10 Days

DT-5K Keyboard Options




The DT-5K combines a Force Sensing Resistor, an upgraded pointing device that offers improved sensitivity and increased durability, with a 10-key numeric keypad in a ruggedized stainless steel case, providing dual functionality in one compact unit. Its 20 function keys provide user versatility. This keyboard also offers user Windows keys for ease of access to the operating system
Specification
Manufacturer or Brand iKey
Mounting Format Desktop, Free Standing, Mobile, Vehicle Mount, VESA, VESA Mount
IP Rating IP66
Interface PS2, USB
Case Material Stainless Steel
Housing Colour Stainless Steel
Backlight No Backlight
Certifications IP Rated, NEMA 4X UL60950, FCC Part 15 Class B
Temperature Rating STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to +60C (-4F to +140F)
Humidity 100% Humidity Resistant
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Dimensions 16.25" x 7.88" x 1.80" (w-h-d) 412.8mm x 200.2mm x 45.7mm
Warranty 1 Year Limited Warranty
Cable Single-Cable USB
Certified European Standards EN60079-0:2009, EN60079-11:2007 and EN60529:1991 + A1:2000
Compatibility All Windows and Macintosh Operating Systems
Entity Parameters Ui = 6.51V, Ii = 730mA, Pi = 1.01W, Ci = 63.23, Li = 2.41uf
Flammability PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO
Function Keys 24 Keys
Hazardous Location Ratings II 3 G Ex ic IIB T4 Ta = 60, IP65
Key Feedback Tactile with Mechanical Snap
Key Material Industrial Silicone Rubber
Key Switch MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 in. (1.4 mm) ACTUATION FORCE: 7.03 oz +/- 1.06 oz (200g +/- 20g) FEEDBACK: Tactile with mechanical snap
Lifespan >10 Million Actuations
Mounting Filter Desktop , VESA
No. Of Keys 113
Pointing Device Force Sensing Resistor
Power PS/2 or AT/Serial: KEYBOARD: 50mA@5V (from Keyboard port) HULAPOINT: 35mA@5V (from Mouse port) USB: 85mA@5V (from CPU port)
Product Weight 5.25 lbs +/- 0.10 lbs (2.38 kg +/- 0.05 kg)
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Switch Force 200g (+/- 20g)
Switch / Key Travel 0.055 in (1.4mm)
Vibration POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
  • Highly-Rugged Stainless Steel Case
  • 113-Key Functionality / 10-Key Numeric Pad
  • Integrated Force Sensing Resistor
  • USB, PS2 and AT/Serial Configurations Available
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request
The iKey DT-5K is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iKey DT-5K Keyboard are listed below:-

  • Cold Store
  • Factory Floor
  • Food Processing
  • Industrial Automation
  • Petrol Stations
  • Smart Factory
  • Warehousing
  • Industry 4.0

These are just some of the applications for the iKey DT-5K Keyboard The potential applications extend further than those shown above. For further information about the iKey DT-5K Keyboard or to check if the product is suitable for your application, please do not hesitate to contact us.
With our highly trained in house technical team and strong relationship with our manufacturers, we can offer numerous options and configurations for the iKey DT-5K Keyboard to suit your requirements. These options include:

  • Keyboard Layout
  • Keyboard Language
  • Cable Type
  • Cable Length
  • Interface

If your application requires unusual or individual modifications not listed above for the iKey DT-5K Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The iKey DT-5K Keyboard has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, iKey DT-5K Keyboard, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
