IK-TR-88-911 USB IK-TR-88-911 PS2 IK-TR-88-911 IP55-RATED IK-TR-88-911 TOUCHPAD IK-TR-88-911 CUSTOMISABLE


IK-PAN-FZG1-NB-C1 iKey Keyboard

IK-PAN-FZG1-NB-C1 iKey Keyboard

iKey-IK-TR-88-911-TP-Keyboard

IK-TR-88-911-TP iKey Keyboard

IK-TR-88-911 iKey Keyboard

This brand new Transformer Keyboard from iKey has been designed with active service in mind to be an ideal on-the-go solution for in-vehicle use by the emergency services.

IK-TR-88-911 Features

  • 88-Key Functionality
  • Integrated LED Backlighting
  • Integrated Touchpad
  • 12 Function Keys
  • Various Keyboard and Language Layout Options

IK-TR-88-911 Keyboard Options



This brand new Transformer Keyboard from iKey has been designed with active service in mind—to be an ideal on-the-go solution for in-vehicle use by the emergency services. Devised with the keywords 'flexibility' and 'versatility' foremost, the IK-TR-88-911-TP offers a host of features that can accommodate a wide range of uses in the field.

To keep things simple, however, and to facilitate an easy introduction of the new keyboard, it has been designed to fit into existing mobile mounting systems—but its range of functions and options gives it the edge over alternative models. With its built-in high-speed USB hubs and modular options, this keyboard can be used for multiple configurations in the field and on the road—and its versatility is one of its key selling points.

The compact keyboard that's fully loaded

The IK-TR-88-911-TP packs a full raft of functions and features into its diminutive case. It has 88-key functionality with 12 dedicated function keys, plus an integrated touchpad and a one-touch emergency key. To facilitate use in poor conditions, the keys are backlit and the rugged case is fully sealed, making it 100% humidity proof. The keypads are made of industrial silicone rubber, with tactile mechanical snap key switches. It is resistant to dirt, dust and moisture and it operates within a temperature range of -20C to +60C. Mobile mounting holes make installation into vehicles easy and it weighs less than a kilo, making it fully portable.

Versatility in the field

The new IK-TR-88-911-TP offers unprecedented flexibility of use and can withstand tough conditions on the road. It can be used on its own or mounted in a vehicle and it represents an excellent solution for military, emergency services, medical, industrial and energy industry applications.



IK-TR-88-911-TP

A compact mobile keyboard that's big on functionality

Specification
Manufacturer or Brand iKey
Mounting Format Desktop, Free Standing, Mobile, Vehicle Mount, VESA, VESA Mount
Interface PS2, USB
Case Material ABS Polycarbonate
Housing Colour Black
Backlight Red
Certifications CE, RoHS compliant
Temperature Rating STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to +60C (-4F to +140F)
Humidity 100% Humidity Resistant
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Dimensions 302.77 x 194.3 x 31.24 mm (11.92 x 7.65 x 1.23 inches)
Warranty 1 Year Limited Warranty
Compatibility All Windows Operating Systems
Flammability PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO
Function Keys 12 Keys
Key Feedback Mechanical
Key Material ABS Plastic
Lifespan >10 Million Actuations
Mounting Filter VESA Mount
No. Of Keys 88
Pointing Device Touchpad
Power USB: 35mA@5V (from CPU port)
Product Weight 2.0 lbs +/- 0.10 lbs (0.90 kg +/- 0.05 kg)
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Vibration POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
  • 88-Key Functionality
  • Integrated LED Backlighting
  • Integrated Touchpad
  • 12 Function Keys
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request
The iKey IK-TR-88-911 is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iKey IK-TR-88-911 Keyboard are listed below:-

  • Factory Floor
  • Industrial Automation
  • Military Tanks
  • Mobile Worker
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the iKey IK-TR-88-911 Keyboard The potential applications extend further than those shown above. For further information about the iKey IK-TR-88-911 Keyboard or to check if the product is suitable for your application, please do not hesitate to contact us.
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the iKey IK-TR-88-911 Keyboard to suit your requirements. These options include:

  • Keyboard Layout
  • Keyboard Language
  • Cable Type
  • Cable Length
  • Interface

If your application requires unusual or individual modifications not listed above for the iKey IK-TR-88-911 Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The iKey IK-TR-88-911 Keyboard has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, iKey IK-TR-88-911 Keyboard, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
