Winmate R15IE3S-PTC3 15 Inch HMI Touch Panel PC
Designed for industrial automation environments, the Winmate R15IE3S-PTC3 15 Inch HMI Touch Panel PC provides a robust interface built for continuous operation in demanding settings. Its 15-inch industrial-grade projected capacitive touchscreen includes an anti-glare coating that ensures clear visibility and sensitive input under various lighting conditions. The front panel is sealed to IP65 standards, protecting internal components from dust and liquid splashes typically found in manufacturing or warehouse areas.
Operating between 0°C and 50°C, this unit features a fanless cooling system aimed at enhancing reliability by reducing mechanical parts prone to failure. The device meets MIL-STD-810 standards, ensuring resistance to vibration and environmental stressors common in industrial deployments. Dual Intel Ethernet controllers offer flexible network connectivity options and TPM 2.0 provides hardware-based security for sensitive applications. The Winmate R15IE3S-PTC3 supports multiple operating systems and connections, making it a field-ready panel PC suited to long-term, sealed industrial use.
R15IE3S-PTC3 Features
- Low power consumption with Intel® Celeron® Elkhart Lake N6211 processor
- Fanless cooling system and ultra-low power consumption
- Front IP65 for protection against water and dust
- A true flat, easy-to-clean front surface with edge-to-edge design
Request a Quote
Product Type
Manufacturer
Ruggedness
Mounting Format
Screen Size
Country Of Manufacture
Taiwan
Size
15.0 inches
Touch / Glass
Projected Capacitive Multi Touch Screen Anti-glare Coating (Optional)
Resolution
1024x768
Panel Brightness
300.0 nits
Contrast Ratio
2000:1
View Angles
88-88-88-88
Active Area
304.1x228.1 mm
Processor
Intel® Celeron® N6211 ( up to 3.0GHz) Intel® Celeron® N6210 (up to 2.6GHz) (Optional)
Memory
1 x SO-DIMM- DDR4 3200 MHz- 4GB 8GB (Optional) 16GB (Optional)
Storage
1 x M.2 2242 B-key SSD 128GB M.2 2242 B-key SSD up to 512GB (Optional) 1 x SATA III for 2.5" SSD/HDD up to 1TB (Optional)
Ethernet controller
2 x Intel® Ethernet Controller
Security
TPM 2.0
Operating System
Windows 11 IoT Enterprise (64 bit) (Optional) Windows 11 Pro 64 bit (Optional) Windows 10 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 22.04 (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
CE- FCC
Dimension
352.5 x 276.7 x 45 mm
Weight
2.41 kg
Mounting
VESA Mount
Enclosure
Plastic
Cooling System
Fanless Design
USB Port
2 x USB3.2 Gen1x1 (Type-A)
Serial Port
1 x RS232(Default)/422/485
LAN
2 x RJ45-10/100/1000 Mbps
Video
1 x HDMI 2.0 (Optional)
Audio
2 x Speaker (Optional)
Indicator
Power LED Indicator
Power Rating
12V DC
Button
1 x Power Button 1 x Reset Button
Accessory
Quick Start Guide(Hardcopy) AC Adapter 12V/50W Power Cord"
The Winmate R15IE3S-PTC3 15 Inch HMI Touch Panel PC is designed and engineered for use in demanding environments where reliability, durability are essential. The R15IE3S-PTC3 supports a wide range of industries and operational applications.
Common deployment industries include: Construction, Defence And Military, Energy and Utilities, Food And Beverage Processing, Industrial Manufacturing, Logistics And Supply Chain, Oil and Gas, Warehousing.
Across these sectors, the R15IE3S-PTC3 is typically used in applications such as Forklift And Materials-Handling Terminals, Industrial HMI And Machine Interfacing, Inventory Management And Stock Control, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, Quality Control And Inspection, SCADA And Control-Room Access, Warehouse Picking And Put-Away.
These examples demonstrate the versatility of the R15IE3S-PTC3 across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the R15IE3S-PTC3 is appropriate for your specific application, please contact us.
The Winmate R15IE3S-PTC3 15 Inch HMI Touch Panel PC comes with a 1 Year RTB UK Warranty With Option To Extend Upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Winmate R15IE3S-PTC3 15 Inch HMI Touch Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the Winmate R15IE3S-PTC3 15 Inch HMI Touch Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Winmate R15IE3S-PTC3 15 Inch HMI Touch Panel PC, or would you like to discuss a customised solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Winmate R15IE3S-PTC3 or need a custom Rugged Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
