RKP-B160 USB RKP-B160 IP65-RATED RKP-B160 CUSTOMISABLE RKP-B160 CUSTOMISABLE

RKP-B139-24 RUGGED Keypad

RKP-B139-24 RUGGED Keypad

RKP-B179 RUGGED Keyboard

RKP-B179 RUGGED Keyboard

RKP-B160 RUGGED Keypad

16 keys compact format IP65 dynamic vandal proof Stainless Steel industrial numeric keypad with industrial metal dome PCB electronics controller shielded & protected by stainless steel housing

RKP-B160 Features

  • Rugged Panel Mount Keypad
  • IP65 Rated
  • Stainless Steel Construction

Manufacturer: RUGGED

RKP-B160 Keypad Options




16 keys compact format IP65 dynamic vandal proof Stainless Steel industrial numeric keypad with industrial metal dome PCB electronics controller shielded & protected by stainless steel housing, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input, rear aluminium plate with mounting holes for rear panel mounting. Backlight optional. Dimensions: 160.0mm x 102.3mm (front panel)
Specification
Manufacturer or Brand RUGGED
Mounting Format Panel Mount
IP Rating IP65
Interface PS2, USB
Case Material Stainless Steel
Certifications RoHS Compliant, CE and FCC, ESD
Operating Temperature Operating temperature:-20C to +60C
Storage Temperature Storage temperature: -30C to +70C
Temperature Rating Operating temperature:-20C to +60C - Storage temperature: -30C to +70C
Humidity 30-90% Humidity Resistant
Dimensions 160.0mm x 102.3mm
Width 160.0mm
Length 102.3mm
Warranty 1 Year Limited Warranty
Compatibility All Windows, Linux, Unix, Mac OSX, Vxworks, Android
EMC IEC 61000-4-2:2008; IEC 61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004
Frontplate Material Brushed Stainless Steel
Key Switch Gold-on-Gold key Switch Technology
Lifespan > 5 Million Actuations
Mounting Filter Panel Mount
MTBF >50000h
MTTR <30min
No. Of Keys 16
Operating Force 1.2N +/-0.1N
Supply Voltage +5V DC +/-5%
Switch / Key Travel 0.45mm
  • Rugged Panel Mount Keypad
  • IP65 Rated
  • Stainless Steel Construction
The RUGGED RKP-B160 is used in a wide range of industries for a broad range of rugged applications. The most common applications for the RUGGED RKP-B160 Keypad are listed below:-

  • Broadcast Consoles
  • Industrial Automation
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the RUGGED RKP-B160 Keypad The potential applications extend further than those shown above. For further information about the RUGGED RKP-B160 Keypad or to check if the product is suitable for your application, please do not hesitate to contact us.
With our highly trained in house technical team and strong relationship with our manufacturers, we can offer numerous options and configurations for the RUGGED RKP-B160 Keypad to suit your requirements. These options include:

  • Cable Type
  • Cable Length
  • Interface
  • Keypad Layout

If your application requires unusual or individual modifications not listed above for the RUGGED RKP-B160 Keypad, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The RUGGED RKP-B160 Keypad has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, RUGGED RKP-B160 Keypad, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
