RKP-B80-40-DWP RUGGED Keypad

40 keys compact format IP67 dynamic vandal proof Stainless Steel industrial numeric keypad with industrial electronics controller included

RKP-B80-40-DWP Features

  • Rugged Panel Mount Keypad
  • IP67 Rated
  • Stainless Steel Construction

RKP-B80-40-DWP Keypad Options



40 keys compact format IP67 dynamic vandal proof Stainless Steel industrial numeric keypad with industrial electronics controller included, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input, industrial backlight optional. (Red/blue/white/green optional), with rear panel mounting solution. Which is good for outdoor application with direct rain and very harsh environments with humidity, much dynamic water, oil, dirt, salt mist etc, no rust risk and anti-salt spray corrosion. Dimensions: 140.0mm x 80.0mm (front panel)

Specification
Manufacturer or Brand RUGGED
Mounting Format Panel Mount
IP Rating IP67
Interface PS2, USB
Case Material Stainless Steel
Housing Colour Stainless Steel
Certifications RoHS Compliant, CE and FCC, ESD
Operating Temperature Operating temperature:-20C to +60C
Storage Temperature Storage temperature - 40C to +70C
Temperature Rating Operating temperature -20C to +60C
Humidity 30-90% Humidity Resistant
Dimensions 140.0mm x 80.0mm
Width 80.0mm
Length 140.0mm
Warranty 1 Year Limited Warranty
Base plate Material Epoxy resin gilding
Compatibility All Windows and Macintosh Operating Systems
EMC IEC 61000-4-2:2008; IEC 61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004
EMI EN 55022: 2010
EMS EN 55024:2010
Frontplate Material 1.5mm Thickness Super Quality Brushed Stainless Steel
Key Material Stainless Steel
Key Spacing 10.0mm x 10.0mm for normal keys
Key Switch Gold-on-Gold key Switch Technology
Lifespan > 5 Million Actuations
Material (Bottom Plate) 1.5mm Thickness Super Quality Stainless Steel
Mounting Filter Panel Mount
MTBF >50000H
MTTR <30min
No. Of Keys 40
Operating Force 2.0N+/-0.1N for key 10.0mm x 10.0mm (pressure point)
Supply Current Under 300mW for operation, under 200mW for non-operation
Supply Voltage +5V DC +/-5%
Switch / Key Travel 0.45mm
  • Rugged Panel Mount Keypad
  • IP67 Rated
  • Stainless Steel Construction
The RUGGED RKP-B80-40-DWP is used in a wide range of industries for a broad range of rugged applications. The most common applications for the RUGGED RKP-B80-40-DWP Keypad are listed below:-

  • Access Control
  • Broadcast Consoles
  • Computer Consoles
  • Industrial Automation
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the RUGGED RKP-B80-40-DWP Keypad The potential applications extend further than those shown above. For further information about the RUGGED RKP-B80-40-DWP Keypad or to check if the product is suitable for your application, please do not hesitate to contact us.
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the RUGGED RKP-B80-40-DWP Keypad to suit your requirements. These options include:

  • Cable Type
  • Cable Length
  • Interface
  • Keypad Layout

If your application requires unusual or individual modifications not listed above for the RUGGED RKP-B80-40-DWP Keypad, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The RUGGED RKP-B80-40-DWP Keypad has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, RUGGED RKP-B80-40-DWP Keypad, must be presented to us here in the UK.
