iKey PMU-5K-TB Panel Mount Rugged Keyboard With Trackball
Designed for industrial control panels and harsh environments, the iKey PMU-5K-TB Panel Mount Rugged Keyboard With Trackball delivers dependable input functionality in sealed, continuous-duty applications. This panel-mount keyboard features an IP-rated, NEMA 4X enclosure that protects against dust, moisture, and humidity, making it suitable for sectors such as manufacturing, aerospace, and oil and gas. It integrates a 25mm trackball with multi-button control to maintain precise cursor movements without using extra workspace. The 116-key layout offers a numeric keypad and 24 function keys to support complex control tasks onsite. Mechanical resilience is established with over 10 million keystroke lifespan and shock resistance tested to MIL-STD-810G standards.
It operates reliably between 0 and +65 degrees Celsius and includes 100% humidity resistance when properly installed. PS/2 compatibility ensures wide integration options, and the 10-foot Y-cable separates keyboard and mouse inputs for flexible connection. The sealed silicone key switches provide tactile feedback with mechanical snap, optimised for rugged deployments requiring reinforced durability and long-term use.
PMU-5K-TB Features
- Integrated Trackball
- MS Windows Function Keys
- 24 Function Keys + 10-Key Numeric Pad
- USB and PS2 Configurations Available
- Various Keyboard and Language Layout Options
- Customisation Available On Request
Request a Quote
Product Type
Manufacturer
Certifications & Standards
Ruggedness
IP Rating
Mounting Format
Country Of Manufacture
United States
Backlight
No Backlight
Case Material
No Case
Certifications
IP Rated, NEMA 4X UL60950
Custom Options Products
Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface
Dimensions
15.39" x 7.06" x 0.50" (w-h-d) 390.9mm x 179.3mm x 12.7mm SCREWS: 0.75" (19.1mm) CUTPIT: 13.52" x 5.18" (w-h) 343.4mm x 131.6mm
Humidity
100% Humidity Resistant (when properly installed)
Cable
LENGTH: 10 feet (3 meters) DESIGN: "Y" PS/2 (providing separate keyboard and mouse connections)
Compatibility
PS/2 KEYBOARD/TRACKBALL: All Windows Operating Systems
Flammability
PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO
Function Keys
24 Keys
Key Feedback
Tactile with Mechanical Snap
Key Material
Industrial Silicone Rubber
Key Switch
MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 6.35 oz. +/- 1.06 oz. (180g +/- 30g) FEEDBACK: Tactile with Mechanical Snap
Lifespan
>10 Million Actuations
No. Of Keys
116
Pointing Device
Trackball
Power
PS2: KEYBOARD: 50mA@5V (from Keyboard port) POINTER: 20mA@5V (from Mouse port) USB: 70mA@5V (from CPU port)
Product Weight
2.00 lbs +/- 0.10 lbs (0.91 kg +/- 0.05 kg)
Shock
3 x 11 ms Pulses of 50g on each of 3 Axes
Switch Force
(180g +/- 30g)
Switch / Key Travel
0.055 in (1.4mm)
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
Shock
3 x 11 ms Pulses of 50g on each of 3 Axes
Temperature Rating
STORAGE: -40C to +85C (-40F to +185F) OPERATING: 0C to +65C (+32F to 149F)
The iKey PMU-5K-TB Panel Mount Rugged Keyboard With Trackball is designed and engineered for use in demanding environments where reliability, durability are essential. The PMU-5K-TB supports a wide range of industries and operational applications.
Common deployment industries include: Aerospace, Defence And Military, Energy and Utilities, Industrial Manufacturing, Marine And Offshore, Offshore Operations, Oil and Gas.
Across these sectors, the PMU-5K-TB is typically used in applications such as Aircraft Cockpit And Avionics Support Systems, ATEX And Hazardous-Area Data Capture, Industrial HMI And Machine Interfacing, Marine Bridge And Vessel Control Systems, Process Control And Shop-Floor Monitoring, Robotics And Autonomous System Control, SCADA And Control-Room Access, Secure Access, Authentication, And Control Terminals.
These examples demonstrate the versatility of the PMU-5K-TB across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the PMU-5K-TB is appropriate for your specific application, please contact us.
The iKey PMU-5K-TB Panel Mount Rugged Keyboard With Trackball comes with a Standard Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iKey PMU-5K-TB Panel Mount Rugged Keyboard With Trackball, must be presented to RUGGED in the United Kingdom.
For more information about the iKey PMU-5K-TB Panel Mount Rugged Keyboard With Trackball or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the iKey PMU-5K-TB Panel Mount Rugged Keyboard With Trackball, or would you like to discuss a customised solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iKey PMU-5K-TB or need a custom Rugged Keyboard solution designed specifically for you, our team of technical experts are ready to assist you.
