At a glance
- Computers is the parent category for several product ranges, from panel PCs and embedded boards to rugged radios and ATEX tablets.
- The category lists 382 products. 105 sit directly in Computers without a range, and some products appear in more than one range.
- The three largest ranges are panel PCs (87 products), embedded computing (78) and ground control stations (66).
- Choose by where the computer will live: behind a screen, in a box or on a board, on a vehicle, in the hand, or in a hazardous area.
- Some tablets and phones are listed for hazardous areas, and the marking and certificate of the exact model must match the zone of your site.
What is in the Computers category?
Computers is the parent category for rugged computing hardware. It does not describe one kind of product, so this guide works as a map. Each range has its own selection guide, and the right one depends on where the computer will be installed and who will use it.
Which range suits which job?
| Range | Products | What it holds | Start here when |
|---|---|---|---|
| Panel PCs | 87 | A computer built behind a touchscreen | You need an operator interface for a panel, rack or arm |
| Industrial PCs | 22 | Complete box PCs, plus vehicle-mount units | You want a finished computer that arrives ready to run |
| Embedded computing | 78 | Fanless systems and board-level parts | You are building the computer into your own product |
| In-vehicle PCs | 8 | Vehicle-mounted computers with touchscreens | The computer must travel on a vehicle |
| Ground control stations | 66 | Complete stations, plus cases, controllers, displays, keyboards and trackballs | You operate unmanned vehicles |
| Rugged radios | 26 | Rugged phones and one radio; 12 list push-to-talk | The need is voice communication |
| ATEX tablets | 12 | Tablets listed for hazardous areas | The device must go into a classified zone |
How do panel PCs, displays and box computers differ?
A panel PC has the computer built behind its screen. Panel mount displays are the screen only and need a separate computer, while panel PC displays holds 22 display-and-PC models from the displays range, all also listed here. Most industrial PCs are boxes that connect to a separate display through their video outputs. Embedded computing runs from fanless boxes down to bare boards. If you are an integrator designing a computer into a product, the OEM rugged computers range is written for that job. For tablets and laptops, see rugged tablets and rugged laptops, and for phones, hotspots and other carried devices, see rugged mobile.
What about hazardous areas?
The ATEX tablets range holds tablets listed for hazardous areas, with the zones stated model by model. A listing is not a blanket approval: the marking and certificate of the exact model must match the zone of your site. Read how to read an Ex marking first. Nothing else in this category should be treated as suitable unless the marking and certificate of that exact model cover your zone.
What to check on the datasheet
- Operating temperature and the supply voltage range.
- Ingress rating, and whether it applies to the front only or to the whole unit.
- Shock and vibration standard and its edition, because the data lists both MIL-STD-810G and MIL-STD-810H.
- Ports: Ethernet, serial, CAN bus, USB and video outputs.
- Processor, memory, storage and the operating systems offered.
- Mounting method and dimensions.
- Display brightness and touch type, where there is a screen.
How do you choose a rugged computer?
- Decide where it is installed: in a panel or rack, on a vehicle, in the hand, or inside your own product.
- Set the environment: temperature, ingress, shock and vibration.
- List the interfaces and supply voltage the host system needs.
- Decide whether you need a finished unit or a part for integration.
- If a hazardous area is involved, start from the zone, then look at ATEX tablets.
- Request the datasheet for each shortlisted model.
What to tell us for a quote
Send the installation location, the environment, the display size if any, the interfaces and supply voltage, the operating system you run, expected volumes and how long the product must stay available.
Related guides and ranges
- Panel PCs
- Industrial PCs
- Embedded computing
- In-vehicle PCs
- ATEX tablets
- IP ratings explained
- Standards cheat sheet
Frequently asked questions
Where do I start if I do not know which computer I need?
Start from where it will be installed. A screen fixed in a panel points to panel PCs, a box in a cabinet to industrial PCs, a part inside your own product to embedded computing, and a vehicle to in-vehicle PCs.
Why do the range counts not add up to 382?
Because 105 products sit directly in Computers without a range, and some sit in more than one range. For example, 17 complete box systems appear in both industrial PCs and embedded computing, and five vehicle-mount units appear in both industrial PCs and in-vehicle PCs.
Why are radios in the Computers category?
They share the category with the computers. Radios are covered in the rugged radios range, which holds rugged phones and one radio, 12 of them listing push-to-talk.
Does the same ingress rating mean the same thing in every range?
Not always. Some panel PCs state IP65 for the front panel only, while vehicle units state a rating for the enclosure. Check where the rating applies, and read the IP ratings guide.
Can any of these computers be used in explosive atmospheres?
Only products whose own data states a hazardous-area marking. Most are in the ATEX tablets range, and a few phones in this category are also listed for ATEX or Class I, II and III Division 2. The marking and certificate of the exact model must match the zone of your site. The ATEX guide explains what the markings mean.
