DELL Latitude 7030 Rugged Extreme Tablet
The DELL Latitude 7030 Rugged Extreme Tablet is the world’s lightest 10-inch fully-rugged Windows tablet, designed for ultimate portability in harsh environments. Weighing just 2.24 lbs, it features a glove-capable, 1000-nit, direct sunlight-readable screen and offers advanced connectivity with Wi-Fi 6E, optional 5G, and discrete GPS. Powered by 12th Gen Intel® Core™ processors, it supports up to 2TB of storage and 32GB of memory, making it perfect for demanding field applications. The dual hot-swappable batteries and extensive rugged certifications (MIL-STD-810H, IP-65) ensure all-day performance and reliability in the toughest conditions.
Latitude 7030 Features
- Powered by 12th Gen Intel® CPUs
- Lightweight and Portable
- IP65 and MIL-STD-810H certified
- NVMe SSDs up to 2TB, up to 32GB LPDDR5 memory and integrated Intel® Iris® Xe graphics.
- Hot-Swappable Dual Batteries
- Sunlight-Readable 1000-nit Display
- Wi-Fi 6E, optional 5G, and discrete GPS
Request for Quote (RFQ)
PROCESSOR OPTIONS
12th Gen Intel® Core™ i3-1210U 12th Gen Intel® Core™ i5-1240U, vPro 12th Gen Intel® Core™ i7-1260U, vPro
OPERATING SYSTEM
Microsoft® Windows 11 2022H2 Pro Microsoft® Windows 11 2021H2 Pro
MEMORY OPTIONS
8 GB LPDDR5 5200MT/s integrated 16 GB LPDDR5 5200MT/s integrated 32 GB LPDDR5 5200MT/s integrated
CHIPSET
Intel® ADL-P PCH
GRAPHICS
Intel® Iris® Xe Graphics (Integrated) for i5 and i7 Intel UHD Graphics (Integrated) for i3
DISPLAY
10.1” 16:10 FHD (1920 x 1200) @ 60 Hz, sRGB 100%, Water/Glove-Capable Touchscreen, Anti-Glare and Anti-Smudge, Polarizer, Corning® Gorilla® Glass, 1000 Nit Outdoor-Readable, Active Pen Support, Passive Pen Support
STORAGE
Primary Drive Options: SSD M.2 2230 PCIe/NVMe Class 35 256 GB SSD M.2 2230 PCIe/NVMe Class 35 512 GB SSD M.2 2230 PCIe/NVMe Class 35 1 TB SSD M.2 2230 PCIe/NVMe Class 25 2 TB SED M.2 2230 PCIe/NVMe Class 35 256 GB SED M.2 2230 PCIe/NVMe Class 35 512 GB
SECURITY
TPM 2.0 FIPS-140-2 Certified / TCG Certified Control Vault 3 Advanced Authentication with FIPS 140-2 Level 3 Certification FIPS (Federal Information Processing Standards) 140-2 certification for TPM Fingerprint Reader with Control Vault 3 Contacted Smart Card and Control Vault 3 Self Encrypting Drive (SED), Opal 2.0 only - PCIe Interface Chassis Intrusion Detection Battery Removal Detection RPMC SPI flash SPI Flash Tamper Detection/Prevention Shunt Circuit Wedge-shaped lock slot (Optional) Contacted Smart Card, NFC, and Control Vault 3 Dell Support Assist Dell Optimizer Dell SafeBIOS Dell Encryption Enterprise Dell Encryption Personal Intel Authenticate with IPT Intel Platform Trust Technology Intel Boot Guard Intel Software Guard (SGX) Intel Trusted Execution Technology (TXT) Intel Total Memory Encryption Multi-Key (TME) (Optional) Dell Data Security and Management Software, Dell Endpoint Security and Management Software Dell Secured Component Verification (availability varies by region, additional purchase required) Dell SafeID (additional purchase required)
DOCKING1
(Docks are optional, sold separately) Dell USB-C Dock - WD19S 130W Vehicle docks
CAMERA OPTIONS
No camera / No microphone User Facing Camera: 5M RGB/VGA IR Camera World Facing Camera: 11M RGB Camera
AUDIO & SPEAKERS
Stereo speakers with Waves MaxxAudio® Pro L/R each 2W (Realtek® ALC3254)
BATTERY OPTIONS
Internal 4-Cell, 36 Wh (800 Wh/L) Lithium Ion Battery, ExpressCharge™ Optional Dual 2-Cell, 18 Whr (36 Wh total 800Wh/L) Lithium Ion replaceable, dual hot-swappable Long Life cycle versions Optional
POWER OPTIONS
65W adapter, USB-C 90W adapter, USB-C, MIL 461F
CONNECTIVITY
Wireless Options10: Intel® Wi-Fi 6E (2.4/5/6 GHz) AX211 2x2, 802.11ax with MIMO + Bluetooth 5.3 Qualcomm® Wi-Fi 6E (2.4/5/6 GHz) WCN6856- DBS 2x2, 802.11ax with MIMO + Bluetooth 5.3 Dell Global 5G (DW5931E), eSIM/SIM GPS: uBlox NEO-M9N, L1 (1575.42 MHz)
PORTS, SLOTS & CHASSIS
Ports: 2 x Type-C Thunderbolt 4 ports with Power Delivery (Internal battery Option) 2 x USB 3.2 Gen 2 DisplayPort Type-C ports with Power Delivery (Hot Swap Battery Option) 1 x USB 3.2 Gen 1 Type-A port with PowerShare (Optional) Expansion I/O Port (top) (Choose from Barcode Scanner, USB 3.2 Gen 1 Type-A, Universal Audio Jack, RJ45 1Gbit Ethernet) Slots: 1 x Micro SD card slot 1 x Micro SIM card slot (Dual battery configurations only) 1 x Wedge-shaped lock slot (Optional) 1 x Smart card reader slot, 1 x NFC reader, Non-slot Chassis: Plastic resin and thermoplastic elastomer (TPE).
DIMENSIONS & WEIGHT (WITH BUMPERS)
Width: 262.50 mm / 10.34” Height: 188 mm / 7.40” Depth: 25.40 mm / 1.00” Starting weight: 1.016 kg / 2.24 lbs Maximum weight (with handle): 1.284 kg / 2.83 lbs
REGULATORY AND ENVIRONMENTAL COMPLIANCE
Regulatory Model: T18G Regulatory Type: T18G001 Energy Star 8.0, EPEAT® Gold13 MIL-STD-810H testing17: Transit drop (48” / 1.22m); single unit), blowing rain, blowing dust, blowing sand, vibration, functional shock, humidity, salt fog (with rubberized keyboard), altitude, explosive atmosphere, solar radiation, thermal shock, freeze/thaw, tactical standby to operational Operating thermal range18: -20°F to 145°F (-29°C to 63°C) Non-operating range: -60°F to 160°F (-51°C to 71°C) IEC 60529 ingress protection17: IP-65 (dust-tight, protected against pressurized water) Hazardous locations certification: ANSI/ISA.12.12.01 certification (Class I, Division 2, Groups A,B,C,D) Electromagnetic interference: MIL-STD-461G
INPUT
Rugged 7030 Tablet Water/Glove-Capable Touchscreen Dell Rugged Active Pen - PN720R (Sold separately) Rugged 7030 Tablet Premium Keyboard (Sold separately
SENSORS
Hall Sensor, Gyroscope, eCompass/Magnetometer, Accelerometer (free fall), Ambient Light Sensor, Proximity Sensor (SAR)
SYSTEMS MANAGEMENT
Dell Power Manager 3.1 or later, Dell Command | Configure 4.10 or later, Dell Command | Monitor 10.9 or later, Dell Command | Update 5.0 or later, Dell Command | Update Catalog, Dell Command | Deploy, Dell Command | Integration Suite for System Center 6.4, Dell Command | Intel® vPro™ Out of Band, 4.4 or later, Dell Command | PowerShell Provider 2.7 or later, Dell Command | Deploy Driver Pack Catalog 1.0 or later
PERIPHERAL ECOSYSTEM
Dell Premium Keyboard, Dell Rotating Hand Strap, Dell Active Pen - PN720R, Dell Rigid Tablet Handle, Dell Shoulder Strap, Dell Magnetic Mount, Dell Flexible Handle, Dell Mobile Stand, Dell Passive Pen, Dell Mobile Battery Charger Additional Dell and third-party accessories available
The DELL Latitude 7030 Rugged Extreme Tablet is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the Latitude 7030 is commonly used:
These examples highlight the versatility of the DELL Latitude 7030 Rugged Extreme Tablet across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Tablet fits your specific needs, please contact us.
The DELL Latitude 7030 Rugged Extreme Tablet comes with a 1 Year Limited With Option to Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, DELL Latitude 7030 Rugged Extreme Tablet, must be presented to RUGGED in the United Kingdom.
For more information about the DELL Latitude 7030 Rugged Extreme Tablet or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the DELL Latitude 7030 Rugged Extreme Tablet or require a custom solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the DELL Latitude 7030 or need a custom Tablet solution designed specifically for you, our team of technical experts are ready to assist you.
