iBASE IPPC19B9-RE Panel PC
Designed for industrial environments, the iBASE IPPC19B9-RE Panel PC provides a reliable computing solution with robust aluminium and steel construction. It supports continuous operation in temperatures ranging from 0 to 50 degrees Celsius when fitted with an SSD, and its fanless design reduces maintenance by limiting moving parts prone to dust ingress. The sealed chassis offers protection against dust and humidity within a 10-90% non-condensing range, ensuring stability in varied conditions.
This 19-inch TFT-LCD panel PC delivers a 1280 x 1024 resolution with resistive touch capability, suitable for field and factory deployments. It features dual GbE LAN ports, multiple USB 2.0 and USB 3.0 connectors, and extensive COM ports, enabling seamless network and device integration. The IPPC19B9-RE also comes with MIL-STD vibration and shock resistance certifications, CE and RoHS compliance, and supports Windows Embedded Standard 7 and Windows 7 Pro for Embedded.
IPPC19B9-RE Features
- Fanless Design Modularized Panel PC
- IP65 Front Panel Protection
- 5-Wire Resistive Touch Panel
- Slim & Compact Design
Request a Quote
Product Type
Manufacturer
Certifications & Standards
CE, IP65, MIL-STD-810H, RoHS
Ruggedness
IP Rating
Mounting Format
Processor
Operating System
Country Of Manufacture
Taiwan
Case Material
Aluminum
Certifications
CE, RoHS compliant
Custom Options Products
Interface,Processor,Memory,Storage,Connections,Operating System
Dimensions
465 x 390 x 118.1
Humidity
10-90% Humidity Resistant (non-condensing)
Operating System
Windows
Operating Temperature
0C~ 50C(with SSD)/ 0C~ 40C(with HDD)
Ordering Info
IPPC19B9-RE 19ï¾€ï¾ Modular Panel PC with resistive touch Intel Core i3-2340UE 1.3GHz CPU, 4GB DDR3-1333 SO-DIMM, 320G HDD, 12V-24V wide range DC input, w/o power adaptor Power adaptor AC 90~240V input, 12V DC output 84W power adaptor IBASE P/N: A005PS084W0050000P
Additional Graphics
VGA
Audio
MIC in/ Line out phone jack
Backlight Lifetime(hrs)
50000
Built-in Speaker/MIC
None
Chassis Material
Aluminum front bezel and SGCC back cover with aluminum heat-sink
Construction
Aluminum front bezel and black steel back cover with aluminum heat-sink
Contrast
41.667361111111
Digital I/O
1x Digital I/O
Display Interface
1x DVI-I
Display Type
19" TFT-LCD
Expansion Slot
2 x PCI slot
HDD
1x 2.5" SATA2
Internal Expansion Bus
1x Mini PCI-E half/full size
Interface
USB
Keyboard/Mouse
None
LAN
2x GbE LAN RJ-45
Light Transmission (%)
81
Luminance (cd/m2)
350
Max. Color
16.7M
Max. Resolution
1280 x 1024
Membrane Control
None
Memory
2x DDR3 1333 SO-DIMM Up to 16GB
Mounting
Panel and VESA 75x75mm / 100x100mm
Mounting Type Filter
VESA, Panel Mount
Onboard Expansion Bus
2x Mini PCI-E half/full size
Operating System Support
Windows Embedded Standard 7, Windows 7 Pro for Embedded
Point of touch
1
Power
1x 3pin DC power connector 1x Power on/off rock switch
Power Button
Rock switch
Power Input
12V~24VDC input
Power Input Range
12V DC
Processor, Chipset
Intel Core i3-2340UE 1.3GHz
Removable Slot
1x CFAST slot
RS-232/422/485 Selectable under BIOS
1
Serial/Parallel
3x D-SUB9 COM1/COM2/COM3
Thermal Design
Fanless
Touch Type
Resistive
Touch Type Filter
Resistive
USB
2x USB 2.0 2x USB 3.0
USB 2.0
4
USB 3.0
0
View Angle (H/V)
170/160
Wireless
Optional Wi-Fi/BT
Processor
Intel
Storage Temperature
-20C~60C
The iBASE IPPC19B9-RE Panel PC is designed and engineered for use in demanding environments where reliability, durability are essential. The IPPC19B9-RE supports a wide range of industries and operational applications.
Common deployment industries include: Construction, Energy and Utilities, Industrial Manufacturing, Logistics And Supply Chain, Public Sector, Rail And Transport, Security And Surveillance, Warehousing.
Across these sectors, the IPPC19B9-RE is typically used in applications such as Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Predictive Maintenance And Condition Monitoring, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, SCADA And Control-Room Access, Utilities Inspection And Meter Reading.
These examples demonstrate the versatility of the IPPC19B9-RE across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the IPPC19B9-RE is appropriate for your specific application, please contact us.
The iBASE IPPC19B9-RE Panel PC comes with a Standard Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE IPPC19B9-RE Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE IPPC19B9-RE Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the iBASE IPPC19B9-RE Panel PC, or would you like to discuss a customised solution?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iBASE IPPC19B9-RE or need a custom Rugged Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
