iBASE IPPC19A9-RE Panel PC
For teams working across industrial and demanding commercial environments, the iBASE IPPC19A9-RE Panel PC offers reliable performance in conditions with temperature changes and dust. Its aluminium chassis paired with an aluminium heat-sink and SGCC back cover delivers effective heat dissipation and chassis strength, supporting stable operation from 0°C to 45°C with humidity tolerance up to 90% non-condensing. The fanless design reduces mechanical failure risks, making it suitable for continuous-duty use.
This 19″ modular Panel PC features an Intel 3rd Generation Core i3-2340UE processor and supports up to 16GB DDR3 memory, with expandable storage options including a 2.5″ SATA HDD and CFAST slot. It offers multiple connectivity options including dual Gigabit Ethernet ports, USB 2.0 and 3.0, digital I/O, and serial ports selectable via BIOS. The resistive touch display supports a 1280 x 1024 resolution visible under various lighting conditions. VESA mounting enables flexible deployment setups, and optional Wi-Fi/Bluetooth add wireless connectivity. CE and RoHS certifications confirm compliance with environmental and safety standards, validating its use in industrial-grade deployments.
IPPC19A9-RE Features
- Modularized Panel PC
- Intel 3rd Generation Core Processor
- IP65 Front Bezel
- Slim & Compact Design
Request a Quote
Product Type
Manufacturer
Ruggedness
IP Rating
Mounting Format
Processor
Operating System
Country Of Manufacture
Taiwan
Case Material
Aluminum
Certifications
CE, RoHS compliant
Custom Options Products
Interface,Processor,Memory,Storage,Connections,Operating System
Dimensions
465 x 390 x 109.5
Humidity
5%-90% @ 45C (non-condensing)
Operating System
Windows
Operating Temperature
0C~ 45C
Ordering Info
IPPC19A9-RE 19ï¾€ï¾ Modular Panel PC with resistive touch Intel Core i3-2340UE 1.3GHz CPU, 4GB DDR3-1333 SO-DIMM, 320G HDD, 12V-24V wide range DC input, w/o power adaptor Power adaptor AC 90~240V input, 12V DC output 84W power adaptor IBASE P/N: A005PS084W0050000P
Additional Graphics
VGA
Audio
1x Line-out micro jack 1x Mic-in micro jack
Backlight Lifetime(hrs)
50000
Built-in Speaker/MIC
None
Chassis Material
Aluminum front bezel and SGCC back cover with aluminum heat-sink
Construction
Aluminum & SPCC
Contrast
41.667361111111
Digital I/O
1x Digital I/O
Display Interface
1x DVI-I
Display Type
19" TFT-LCD
Expansion Slot
2x PCI slot
HDD
1x 2.5" SATA
Internal Expansion Bus
1x Mini PCI-E half/full size
Interface
USB
Keyboard/Mouse
None
LAN
2x RJ45 for GbE LAN
Light Transmission (%)
81
Luminance (cd/m2)
350
Max. Color
16.7M
Max. Resolution
1280 x 1024
Membrane Control
None
Memory
2x DDR3 1333 SO-DIMM up to 16GB
Mounting
Panel and VESA 75x75mm / 100x100mm
Mounting Type Filter
VESA, Panel Mount
Onboard Expansion Bus
2x Mini PCI-E half/full size
Operating System Support
Windows Embedded Standard 7, Windows 7 Pro for Embedded
Point of touch
1
Power
1x 3pin DC power connector
Power Button
Rock switch
Power Input
12~24V DC input
Power Input Range
12V DC
Processor, Chipset
Intel Core i3-2340UE 1.3 GHz
Removable Slot
1x CFAST slot
RS-232/422/485 Selectable under BIOS
1
Serial/Parallel
3x DB9 for COM1/2(RS-232/422/485), COM 3 (RS-232 only)
Thermal Design
Fanless
Touch Type
Resistive
Touch Type Filter
Resistive
USB
4x USB connector; USB 1/2 USB 2.0 only, USB 3/4 USB 3.0
USB 2.0
4
USB 3.0
0
View Angle (H/V)
170/160
Wireless
Optional Wi-Fi/BT
Processor
Intel
Storage Temperature
-20C ~ 80C
The iBASE IPPC19A9-RE Panel PC is designed and engineered for use in demanding environments where reliability, durability are essential. The IPPC19A9-RE supports a wide range of industries and operational applications.
Common deployment industries include: Construction, Energy and Utilities, Industrial Manufacturing, Marine And Offshore, Natural Resources and Mining, Oil and Gas, Public Sector, Security And Surveillance.
Across these sectors, the IPPC19A9-RE is typically used in applications such as Digital Signage And Information Terminals, Industrial HMI And Machine Interfacing, Medical Carts And Clinical Mobile Workstations, Process Control And Shop-Floor Monitoring, Rail Operations And Wayside Maintenance, Temporary Deployments And Mobile Command Units.
These examples demonstrate the versatility of the IPPC19A9-RE across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the IPPC19A9-RE is appropriate for your specific application, please contact us.
The iBASE IPPC19A9-RE Panel PC comes with a Standard Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE IPPC19A9-RE Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE IPPC19A9-RE Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the iBASE IPPC19A9-RE Panel PC, or would you like to discuss a customised solution?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iBASE IPPC19A9-RE or need a custom Rugged Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
