BT-87-TP iKey Keyboard

Bluetooth-Compatible, Wireless Industrial Keyboard With Touchpad From iKey Keyboards

BT-87-TP Features

  • Wireless Bluetooth
  • Up To 30-Foot Range
  • 12 Function Keys
  • Integrated Touchpad
  • Various Keyboard and Language Layout Options

Manufacturer: iKey

Availabilty: Est. 5 - 10 Days

BT-87-TP Keyboard Options





iKey introduces the first Bluetooth;-compatible, wireless industrial keyboard with an integrated touchpad - the BT-87-TP. This fully-sealed keyboard is designed to meet NEMA 4X specifications, meaning it is resistant to dirt, dust, water, ice and corrosives.

Built with an industrial silicone rubber keypad and a rugged ABS polycarbonate case, the BT-87-TP is submersible and easy to clean with disinfectants. The compact design and internal Bluetooth; module make the BT-87-TP highly portable. It is an ideal fit for mobile, material handling, food and beverage processing, medical, and other environments where rugged flexibility is a necessity.

The BT-87-TP requires 2 AA batteries for power and does not require a USB dongle if your computer has an internal Bluetooth; radio.

Specification
Manufacturer or Brand iKey
Mounting Format Desktop, Free Standing
IP Rating IP66
Interface Bluetooth
Case Material ABS Polycarbonate
Housing Colour Black
Backlight No Backlight
Certifications IP Rated, NEMA 4X
Temperature Rating STORAGE: -40C to +65C (-40F to +149F) OPERATING: 0C to +60C (+32F to +140F)
Humidity 100% Humidity Resistant
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Dimensions 12.01" x 7.75" x 2.03" (w-h-d) 305.54 mm x 196.85 mm x 51.56 mm
Warranty 1 Year Limited Warranty
Cable LENGTH: 5.4' straight (1.6 m) DESIGN: Single cable USB
Compatibility All Windows Operating Systems
Connectivity Wireless , Bluetooth
Flammability PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO
Function Keys 12 Keys
Key Feedback Tactile with Mechanical Snap
Key Material Industrial Silicone Rubber
Key Switch MATERIAL: Industrial Silicone Rubber LIFE: Greater Than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.03 oz +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap
Lifespan >10 Million Actuations
Mounting Filter Desktop
No. Of Keys 87
Pointing Device Touchpad
Power Bluetooth : 2 AA Batteries
Product Weight 2.00 lbs +/- 0.10 lbs (0.91 kg +/- 0.05 kg)
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Switch Force 200g (+/- 30g)
Switch / Key Travel 0.055 in (1.4mm)
Vibration POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
  • Wireless Bluetooth
  • Up To 30-Foot Range
  • 12 Function Keys
  • Integrated Touchpad
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request
The iKey BT-87-TP is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iKey BT-87-TP Keyboard are listed below:-

  • Accident and Emergency
  • Clinical Engineering
  • Dental Surgeries
  • Factory Floor
  • Field Service
  • Hospitals
  • In Vehicle
  • Industrial Automation
  • Medical Carts
  • Mobile Worker
  • Pharmacy
  • Radiology
  • Smart Factory
  • Theatres
  • Vehicle Diagnostic
  • Veterinary Hospitals
  • Ward Areas
  • Doctors Surgeries
  • Industry 4.0

These are just some of the applications for the iKey BT-87-TP Keyboard The potential applications extend further than those shown above. For further information about the iKey BT-87-TP Keyboard or to check if the product is suitable for your application, please do not hesitate to contact us.
With our highly trained in house technical team and strong relationship with our manufacturers, we can offer numerous options and configurations for the iKey BT-87-TP Keyboard to suit your requirements. These options include:

  • Keyboard Layout
  • Keyboard Language
  • Cable Type
  • Cable Length
  • Interface

If your application requires unusual or individual modifications not listed above for the iKey BT-87-TP Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The iKey BT-87-TP Keyboard has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, iKey BT-87-TP Keyboard, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
