iKey SLP-86-911-FSR Panel Mount Backlit Rugged Keyboard

The iKey SLP-86-911-FSR Panel Mount Backlit Rugged Keyboard is engineered with a fully sealed, ingress-protected construction, making it well-suited for industrial and demanding field environments. It is designed for continuous operation and features integrated backlighting to support use in low-light conditions, all within a robust ABS polycarbonate enclosure for long-term durability.

The industrial-grade silicone rubber keys provide tactile feedback with a mechanical snap action, enabling accurate and responsive input. Its integrated Force Sensing Resistor (FSR) pointing device is resistant to impact and tolerant to vibration, making it particularly effective in mobile or high-vibration applications.

When properly sealed, the unit meets NEMA 4X standards and complies with CE and RoHS requirements. It has been tested to MIL-STD-810 for shock and vibration resistance and operates reliably within a temperature range of -20°C to 60°C. With the ability to withstand 100% humidity, it is built to perform consistently in harsh and challenging environments.

SLP-86-911-FSR Features

  • 12 Function Keys
  • 86-Key Functionality
  • Integrated Backlighting
  • Integrated Force Sensing Resistor Pointing Device
  • One-Touch Emergency Key

Request a Quote

Manufacturer

Certifications & Standards

Ruggedness

IP Rating

Mounting Format

Country Of Manufacture

United States

Backlight

Red

Case Material

ABS Polycarbonate

Certifications

CE, RoHS compliant

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

11.80" x 6.79" x 1.35" (w-h-d) 299.7mm x 172.5mm x 34.3mm CUTOUT: 10.40" x 5.40" (w-h) 264.2mm x 137.2

Housing Colour

Black

Humidity

100% Humidity Resistant

Cable

LENGTH: 4 feet (1.2 meters) DESIGN: "Y" PS/2 Cable (providing separate keyboard and mouse connections), or Single-Cable USB

Compatibility

USB: All Windows and Macintosh OS

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94 HB INTERFACE CABLE: 94 VO

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.05 oz. +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap

Lifespan

>10 Million Actuations

No. Of Keys

86

Pointing Device

Force Sensing Resistor

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

200g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40F to +158F (-40C to +70C) OPERATING: -4F to +140F (-20C to +60C)

The iKey SLP-86-911-FSR Panel Mount Backlit Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The SLP-86-911-FSR supports a wide range of industries and operational applications.

Common deployment industries include: Construction, Defence And Military, Emergency Services, Energy and Utilities, Industrial Manufacturing, Marine And Offshore, Offshore Operations, Oil and Gas.

Across these sectors, the SLP-86-911-FSR is typically used in applications such as And Control Terminals, And GIS Data Capture, Authentication, Emergency Dispatch And Incident Management, Industrial HMI And Machine Interfacing, Mapping, Mobile Workforce Operations, Process Control And Shop-Floor Monitoring, Secure Access, Secure Communications And Command-And-Control, Surveying, Vehicle-Mounted Computing (MDTs / VMCs).

These examples demonstrate the versatility of the SLP-86-911-FSR across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the SLP-86-911-FSR is appropriate for your specific application, please contact us.

The iKey SLP-86-911-FSR Panel Mount Backlit Rugged Keyboard comes with a 3 Years Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey SLP-86-911-FSR Panel Mount Backlit Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey SLP-86-911-FSR Panel Mount Backlit Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey SLP-86-911-FSR Panel Mount Backlit Rugged Keyboard, or would you like to discuss a customised solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iKey SLP-86-911-FSR or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
