MB961 iBASE Motherboard

MB961 Features

Original OEM Module
Rohs Compliant, CE
12X PCI, 2X ISA
Led Power Indicators For +5V, -5V, +12V, -12V, 3.3V, +5Vsb
Size: 264.2mm X 311.2mm (10.4"X 12.3")

Overview

The MB961 is a Micro ATX Motherboard based on the 3rd Generation Intel Core i7/i5/i3 processors that are built on a new 22nm manufacturing process.

Specifications

Specification
Manufacturer or Brand	iBASE
Mounting Format	OEM
Form Factor	MIcro-ATX
Processor	Intel
Certifications	RoHS Compliant, CE
Operating Temperature	0C~60C (32CF~140CF)
Storage Temperature	-20C~80C (-4CF~176CF)
Humidity	90% Humidity Resistant (non-condensing @ 60C)
Dimensions	244mm x 244mm (9.6" x 9.6")
Warranty	Standard Manufacturers Limited Warranty + Option to Extend
Ordering Info	MB961RF LGA1155 Q67 Micro ATX motherboard with HDMI, DVI-I and LVDS, Dual Gigabit LAN, 2x SATA III, 2x SATA II, 1x PCI-E(16x), 1x PCI-E(4x), 2x PCI, RAID, iSMART MB961F LGA1155 H61 Micro ATX motherboard with HDMI, DVI-I and LVDS, Dual Gigabit LAN, 4x SATA II,1x PCI-E(16x), 1x PCI-E(4x), 2x PCI, iSMART MB961 LGA1155 H61 Micro ATX motherboard with LPT, Dual Gigabit LAN, 4x SATA II,1x PCI-E(16x),1x PCI-E(4x), 2x PCI, iSMART
Audio	Intel H61/Q67 PCH built-in HD audio + Realtek ALC892 codec
BIOS	AMI
Display Interface	Supports DVI-I, HDMI, 24 bit dual channel LVDS (MB961RF/F)
Expansion Slots	1x PCI-E(x16), 1x PCI-E(x8) [PCI-E(4x) Link], 2x PCI
Form Factor FILTER	ATX
H/W Monitor	Yes
I/O Chipset	Fintek F81866AD-I 3x RS232, 1x RS232/422/48 (jumperless selection) 2x SATA II + 2x SATA III (MB961RF) or 4x SATA II (MB961F), LPT (MB961)
LAN Connector	RJ-45 on board
LAN Controller	1x Intel 82579V Gigabit LAN 1x Realtek RTL8111E Gigabit LAN
Others	Digital I/O(4-in/4-out), iSMART, RAID (MB961RF only)
System Memory	2x DDR3 DIMM Max. 16GB (Non-ECC)
System Speed	up to 3.4GHz
USB	2 ports on board (USB 3.0) MB961F: 4 ports on board + 6 ports via pin header (USB 2.0) MB961RF: 4 ports on board + 8 ports via pin header (USB 2.0)
VGA Controller	Intel 3rd Gen. Core i7 / i5 / i3 / Pentium / Celeron Processor Integrated
VGA Memory	Max. Shared Memory - 1024 MB
Watchdog Timer	256 levels

Downloads

Key Features

Original OEM Module
Rohs Compliant, CE
12X PCI, 2X ISA
Led Power Indicators For +5V, -5V, +12V, -12V, 3.3V, +5Vsb
Size: 264.2mm X 311.2mm (10.4"X 12.3")

Applications

The iBASE MB961 is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iBASE MB961 Motherboard are listed below:-

Industrial Automation

Manufacturing Plant

Smart Factory

Industry 4.0

These are just some of the applications for the iBASE MB961 Motherboard The potential applications extend further than those shown above. For further information about the iBASE MB961 Motherboard or to check if the product is suitable for your application, please do not hesitate to contact us.

Custom Options

Currently there are no custom options listed for the iBASE MB961 Motherboard on our website.

If your application requires unusual or individual modifications for the iBASE MB961 Motherboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

Warranty

The iBASE MB961 Motherboard has a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, iBASE MB961 Motherboard, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
