MI957 Features

  • Original OEM Module
  • Rohs Compliant, CE

Manufacturer: iBASE




The Intel Core i7-610E processor-based MI957 Mini-ITX motherboard supports the mobile Intel QM57 Express Chipset. MI957 is designed for applications requiring high-level processing and graphics performance with a long product life such as those in digital signage, gaming, POS, kiosk and multimedia sectors.
Specification
Manufacturer or Brand iBASE
Mounting Format OEM
Form Factor Mini-ITX
Processor Intel
Certifications RoHS Compliant, CE
Operating Temperature 0C~60C (32CF~140CF)
Storage Temperature -20C~80C (-4CF~176CF)
Humidity 90% Humidity Resistant (non-condensing @ 60C)
Dimensions 170mm x 170mm (6.7" x 6.7")
Warranty Standard Manufacturers Limited Warranty + Option to Extend
Ordering Info MI957-i3 Intel Core i3-330E (2.13GHz) QM57 MiniITX motherboard w/ VGA, DVI, HDMI, DP and Gigabit LAN MI957-i7 Intel Core i7-610E (2.53GHz) QM57 MiniITX motherboard w/ VGA, DVI, HDMI, DP and Gigabit LAN, iAMT 6.0
Audio Intel QM57 built-in audio w/ Realtek ALC888 codec for 5.1CH
BIOS AMI
Display Interface Onboard CRT, DVI-D & 24-bit single channel LVDS, HDMI, DisplayPort
Expansion Slots 1x PCI, 1x PCI-E (x1), 1x Mini PCI-E
Form Factor FILTER Mini-ITX
H/W Monitor Yes
I/O Chipset Fintek F81865-I 1x KB, 1x mouse, 1x LPT, 3x RS-232, 1x RS-232/422/485, 4x SATA II
LAN Connector RJ-45 on board
LAN Controller Intel 82577LM Gigabit LAN
Others Digital I/O (4-in/4-out), +12V DC In
System Memory 2x DDR3 DIMM, 800/1066MHz, Max. 8GB, supports ECC
System Speed 2.53GHz
USB 4 ports on board Pin header for 8 ports (USB 2.0)
VGA Controller Intel Core i7-610E / i3-330E integrated
VGA Memory Max. shared memory - 352MB
Watchdog Timer 256 levels
  • Original OEM Module
  • Rohs Compliant, CE
The iBASE MI957 is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iBASE MI957 Motherboard are listed below:-

  • Industrial Automation
  • IOT
  • Manufacturing Plant
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the iBASE MI957 Motherboard The potential applications extend further than those shown above. For further information about the iBASE MI957 Motherboard or to check if the product is suitable for your application, please do not hesitate to contact us.
Currently there are no custom options listed for the iBASE MI957 Motherboard on our website.

If your application requires unusual or individual modifications for the iBASE MI957 Motherboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The iBASE MI957 Motherboard has a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, iBASE MI957 Motherboard, must be presented to us here in the UK.
