RUGGED RKB-M460-TB-KP-FN-BL-BT Industrial Rugged Keyboard

  • MIL STD 810G
  • IP65 RATED
  • SHOCK
  • DUSTPROOF
  • TRACKBALL
  • KEYBACKLIGHT
  • WIDE TEMPERATURE
  • CUSTOMISABLE

Designed for industrial and rugged field environments, the RUGGED RKB-M460-TB-KP-FN-BL-BT Industrial Rugged Keyboard provides durable, precise input under harsh conditions. It features an IP65-rated sealed design with a 1.5mm stainless steel top panel electroplated with black titanium for corrosion resistance and wear durability. Carbon-on-gold key switch technology delivers quiet, tactile keystrokes with 1.5mm travel, optimising fast data entry. The keyboard integrates a 38mm trackball and full function keys, supporting control in compact or mobile workspaces.

Backlit keys with adjustable lighting improve usability in varying light levels, while a red key lock enables secure cleaning without removal. Certified to IEC 61000 EMC standards and tested against MIL-STD-810G for shock and vibration resistance, this keyboard operates reliably between -20°C and +60°C. With over five years of continuous use expectancy and compatibility across multiple operating systems, it suits demanding industrial, aerospace, and defence deployments requiring sealed, reinforced input devices.

RKB-M460-TB-KP-FN-BL-BT Features

  • Rugged Panel Mount Keyboard
  • Integrated Trackball
  • IP65 Rated
  • Stainless Steel /Plastic Construction

Request a Quote

Manufacturer

Certifications & Standards

Ruggedness

IP Rating

Mounting Format

Country Of Manufacture

China

Case Material

Silicone Rubber

Certifications

RoHS, CE and FCC, ESD

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

460.0mm x 129.5mm

Humidity

90% Humidity Resistant

Cable

Single-Cable Appx. 2.2 to 2.5m

Compatibility

All Windows, Linux, Unix, Mac OSX, Vxworks, Android

Dimension with Trackball

380.0mm x 129.5mm

EMC

IEC 61000-4-2:2008; IEC 61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004

EMI

EN 55022: 2010

EMS

EN 55024:2010

Flammability

PRINTED CIRCUIT BOARD: 94 VOSILICONE OVERLAY: 94 HBINTERFACE CABLE: 94 V

Frontplate Material

1.5mm Stainless Steel Plate With Super Quality Durable Black Titanium Electroplated

Height

20.0mm

Key Spacing

11.4mm x 11.4mm for normal keys, 11.4mm x 24.3mm for enter key, 11.4mm x 71.8mm for space bar.

Key Switch

Carbon-on-Gold key Switch Technology

Lifespan

> 5 years

Material (Bottom Plate)

1.5mm Stainless Steel Plate

MTBF

>50000H

MTTR

<30min

No. Of Keys

106

Operating Force

0.8 N+/-0.1N for normal key with 12.0mm x 13.0mm(pressure point), 1.6 N+/-0.1N for key 23.4mm x 13.0mm (pressure point)

Pointing Device

Trackball

Resolution

400 DPI

Shock

3x11 ms pulses of 50g on each of 3 axes

Supply Current

50mA for keyboard and trackball without backlight. 250mA for keyboard and trackball with backlight on.

Supply Voltage

+5V DC +/-5%

Switch / Key Travel

1.50mm

Trackball Diameter

38mm

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz, FREQUENCY RANGE: 20Hz - 2kHz, DURATION OF TEST PER AXIS: 3 hours

Length

460.0mm

Operating Temperature

Operating temperature:-20C to +60C

Shock

3x11 ms pulses of 50g on each of 3 axes

Storage Temperature

Storage temperature: -30C to +70C

Temperature Rating

Operating temperature:-20C to +60C - Storage temperature: -30C to +70C

Width

129.5mm

The RUGGED RKB-M460-TB-KP-FN-BL-BT Industrial Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The RKB-M460-TB-KP-FN-BL-BT supports a wide range of industries and operational applications.

Common deployment industries include: Aerospace, Defence And Military, Emergency Services, Energy and Utilities, Industrial Manufacturing, Marine And Offshore, Oil and Gas, Rail And Transport.

Across these sectors, the RKB-M460-TB-KP-FN-BL-BT is typically used in applications such as Industrial HMI And Machine Interfacing, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, Quality Control And Inspection, Secure Access, Authentication, And Control Terminals, Security And Surveillance Operations.

These examples demonstrate the versatility of the RKB-M460-TB-KP-FN-BL-BT across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the RKB-M460-TB-KP-FN-BL-BT is appropriate for your specific application, please contact us.

The RUGGED RKB-M460-TB-KP-FN-BL-BT Industrial Rugged Keyboard comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, RUGGED RKB-M460-TB-KP-FN-BL-BT Industrial Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the RUGGED RKB-M460-TB-KP-FN-BL-BT Industrial Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the RUGGED RKB-M460-TB-KP-FN-BL-BT Industrial Rugged Keyboard, or would you like to discuss a customised solution?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the RUGGED RKB-M460-TB-KP-FN-BL-BT or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
