RKP-D80-19 RUGGED Keypad

19 keys compact format IP65 dynamic water proof industrial membrane keypad with industrial electronics controller included

RKP-D80-19 Features

  • Rugged Panel Mount Keypad
  • IP65 Rated
  • Stainless Steel Construction

RKP-D80-19 Keypad Options

19 keys compact format IP65 dynamic water proof industrial membrane keypad with industrial electronics controller included, industrial OMRON switch technology with short stroke 0.45mm with extremely good tactile feeling for reliable data input, surface mounted extremely flush with anti-microbial functionalities, the fonts printed on the film underneath will never fade, durable and scratch-proof polyester withstand to most chemicals and liquids under the harshest environments, ruggedized and backed with 3.0mm Aluminium plate with sand blasting & oxygenation treatment, with top panel mounted solution, industrial level. Dimensions: 80.0mm x 143.0mm (L x W)

Manufacturer or Brand RUGGED
Mounting Format Panel Mount
IP Rating IP65
Interface PS2, USB
Case Material Stainless Steel
Housing Colour Stainless Steel
Certifications RoHS , CE, FCC, ESD
Operating Temperature Operating temperature:-20C to +60C
Storage Temperature Storage temperature: -30C to +70C
Temperature Rating Operating temperature:-20C to +60C (industrial level)-40C to +85C Storage temperature: :-30C to +70C (industrial level)-55C to +150C
Humidity 90% Humidity Resistant
Dimensions 80.0mm x 143.0mm
Width 143.0mm
Length 80.0mm
Warranty 1 Year Limited Warranty
Base plate Material Epoxy resin gilding
Compatibility All Windows, Linux, Unix, Mac OSX, Vxworks, Android
EMC EMC directive 89/336/EEC EN55022: 1988+A1:2000+A2:2003 EN55024: 1988+A1: 2001+A2:2003
EMI EN 50081-1
EMS EN 50081-1
Frontplate Material 1.5mm Thickness Super Quality Brushed Stainless Steel
Key Material Stainless Steel
Key Spacing 12.0mm X 13.0mm for normal keys, 22.5mm x 13.0mm for enter key
Key Switch Carbon-on-Gold key Switch Technology
Lifespan > 3 years
Material (Bottom Plate) Back Stainless Steel Housing: 1.0mm Thickness Super Quality Stainless Steel
Mounting Filter Panel Mount
MTBF >50000H
MTTR <30min
No. Of Keys 19
Operating Force 2.0N+/-0.1N for key 14.0mm x 14.0mm (pressure point)
Supply Current 20mA (non-backlight), 140mA (with backlight on)
Supply Voltage +5V DC +/-5%
Switch / Key Travel 1.5mm
  • Rugged Panel Mount Keypad
  • IP65 Rated
  • Stainless Steel Construction
The RUGGED RKP-D80-19 is used in a wide range of industries for a broad range of rugged applications. The most common applications for the RUGGED RKP-D80-19 Keypad are listed below:-

  • Access Control
  • Broadcast Consoles
  • Computer Consoles
  • Industrial Automation
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the RUGGED RKP-D80-19 Keypad The potential applications extend further than those shown above. For further information about the RUGGED RKP-D80-19 Keypad or to check if the product is suitable for your application, please do not hesitate to contact us.
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the RUGGED RKP-D80-19 Keypad to suit your requirements. These options include:

  • Cable Type
  • Cable Length
  • Interface
  • Keypad Layout

If your application requires unusual or individual modifications not listed above for the RUGGED RKP-D80-19 Keypad, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The RUGGED RKP-D80-19 Keypad has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, RUGGED RKP-D80-19 Keypad, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
