RUGGED RTP-BTN-MOUNT Stainless Steel Touchpad

Designed for industrial control panels, the RUGGED RTP-BTN-MOUNT Stainless Steel Touchpad provides a robust user interface built to endure harsh environments. Its impact-resistant stainless steel casing ensures corrosion resistance and long operational life. The touchpad features an IP65 sealed design protecting against dust and water jets, making it suitable for outdoor and industrial applications. It supports USB and PS/2 connections and is compatible with several operating systems including Windows, Linux, and Mac, offering versatile integration.

This touchpad is engineered for continuous operation, withstanding vibration and temperature extremes from -40°C to +70°C, fitting demanding industrial conditions. Certified to CE, FCC, and RoHS standards, it assures compliance and reliability. With a lifespan exceeding five years and vibration tests aligned with power spectral density criteria, it suits extended deployments requiring reliable and stable data entry over time.

RTP-BTN-MOUNT Features

  • Industrial Grade Stainless Steel
  • IP65 Rated
  • Suitable for Industrial & Public Environments
  • UK RTB Warranty

Request a Quote

IP Rating

Operating System

Manufacturer

Country Of Manufacture

China

Case Material

Stainless Steel

Certifications

CE, FCC, RoHS Compliant

Custom Options Products

Cable Type,Cable Length,Interface

Dimensions

80 x 80mm (front panel)

Extended Warranty

Available On Request

Housing Colour

Stainless Steel

Certified European Standards

CE, FCC, RoHS Compliant

Colour

Stainless Steel

Compatibility

DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/7,8,10 Linux, Mac,etc

Dimensions

478*135mm (front panel)Rear Panel: 502*159mm

MTBF

>50000H

MTTR

<30min

No. Of Keys

2

Supply Voltage

+5V DC +/-5%

Switch / Key Travel

0.4mm

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Lifetime

Lifespan > 5 years

Operating System

IOS,Linux,Windows,Windows 10 IOT

Operating Temperature

OPERATING: -40C to +70C (-40F to +158F)

Storage Temperature

STORAGE: -50C to +80C

The RUGGED RTP-BTN-MOUNT Stainless Steel Touchpad is designed and engineered for use in demanding environments where reliability, durability are essential. The RTP-BTN-MOUNT supports a wide range of industries and operational applications.

Common deployment industries include: Construction, Defence And Military, Energy and Utilities, Industrial Manufacturing, Logistics And Supply Chain, Marine And Offshore, Natural Resources and Mining, Oil and Gas.

Across these sectors, the RTP-BTN-MOUNT is typically used in applications such as Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Process Control And Shop-Floor Monitoring, Quality Control And Inspection, SCADA And Control-Room Access, Secure Access, Authentication, And Control Terminals.

These examples demonstrate the versatility of the RTP-BTN-MOUNT across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the RTP-BTN-MOUNT is appropriate for your specific application, please contact us.

The RUGGED RTP-BTN-MOUNT Stainless Steel Touchpad comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, RUGGED RTP-BTN-MOUNT Stainless Steel Touchpad, must be presented to RUGGED in the United Kingdom.

For more information about the RUGGED RTP-BTN-MOUNT Stainless Steel Touchpad or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the RUGGED RTP-BTN-MOUNT Stainless Steel Touchpad or require a custom solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the RUGGED RTP-BTN-MOUNT or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
