iKey SK-79-OEM Rugged Keyboard

This product has reached End of Life (EOL) status and is no longer in production. Manufacturer support, updates, and spare parts may be discontinued.

All information is provided for reference only. Availability cannot be guaranteed.

Please contact us to discuss current alternatives or recommended replacement models.

The iKey SK-79-OEM Rugged Keyboard is built around a tactile mechanical snap key switch design, supporting compact deployments in harsh field environments. Its sealed enclosure withstands dust and water ingress with NEMA 4X and IP68 certification, making it suitable for continuous-duty use in industrial and outdoor settings. The keyboard integrates a HulaPoint II pointing device with dual left-click functionality without expanding its ultra-small footprint. Constructed from industrial silicone rubber with a silicone overlay, it resists 100% humidity when installed correctly. Its shock and vibration tolerance comply with MIL-STD-810G, ensuring durability under mechanical stresses.

The device operates reliably across a wide temperature range from -20°C to +60°C, meeting varied environmental demands. Connectivity options include PS/2 and USB compatible with Windows and Macintosh systems. Key lifespan exceeds 10 million cycles, reflecting its industrial-grade endurance and precision in demanding applications.

SK-79-OEM Features

  • 12 Function Keys
  • Integrated Pointing Device
  • Dual Left Click Function
  • Meets NEMA 4X (IP66) Specifications
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

Manufacturer

Certifications & Standards

Ruggedness

IP Rating

Mounting Format

Country Of Manufacture

United States

Backlight

No Backlight

Case Material

No Case

Certifications

NEMA 4X, CE UL60950, FCC Part 15 Class B

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

9.00" x 3.60" x 0.45" (w-h-d) 228.6mm x 91.4mm x 11.4mm

Housing Colour

Black

Humidity

100% Humidity Resistant (when properly installed)

Cable

3' (0.91 m)

Compatibility

PS/2: All Windows Operating Systems USB: All Windows and Macintosh OS

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO

Function Keys

10 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. ACTUATION FORCE: 135g FEEDBACK: Tactile with Mechanical Snap

Lifespan

>10 Million Actuations

No. Of Keys

79

Pointing Device

HulaPoint

Power

PS/2: KEYBOARD: 50mA@5V (from Keyboard port) POINTER: 35mA@5V (from Mouse port) USB: 85mA@5V (from CPU port)

Product Weight

0.75 lbs (0.34 kg)

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

135g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to +60C (-4F to +140F)

The iKey SK-79-OEM Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The SK-79-OEM supports a wide range of industries and operational applications.

Common deployment industries include: Construction, Defence And Military, Emergency Services, Energy and Utilities, Industrial Manufacturing, Marine And Offshore, Offshore Operations, Oil and Gas.

Across these sectors, the SK-79-OEM is typically used in applications such as Emergency Dispatch And Incident Management, Fleet Management And Telematics, Industrial HMI And Machine Interfacing, Process Control And Shop-Floor Monitoring, SCADA And Control-Room Access, Secure Access, Authentication, And Control Terminals, Secure Communications And Command-And-Control, Vehicle-Mounted Computing (MDTs / VMCs).

These examples demonstrate the versatility of the SK-79-OEM across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the SK-79-OEM is appropriate for your specific application, please contact us.

The iKey SK-79-OEM Rugged Keyboard comes with a 90 Day Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey SK-79-OEM Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey SK-79-OEM Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey SK-79-OEM Rugged Keyboard, or would you like to discuss a customised solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iKey SK-79-OEM or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
