TSW100 Teltonika Industrial POE+ Ethernet Switch
TSW100 is an unmanaged Gigabit Ethernet switch supporting Power-over-Ethernet. Classified as power source equipment (PSE), it centralizes the power supply, providing up to 30 watts per port and reducing installation effort. Five Gigabit Ethernet ports provide an economical high-bandwidth solution for a secure industrial Ethernet network.
TSW100 Features
- 4 x PoE+ ports with 802.3af and 802.3at support
- Total power budget at PSE up to 120 W
- 5 x Gigabit Ethernet with speeds up to 1000 Mbps
- DIN rail and surface mounting options
Request for Quote (RFQ)
Product Type
Format
Manufacturer
Country Of Manufacture
Lithuania
ETH
5 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
IEEE 802.3 series standards
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
PoE ports
Port 1-4
PoE standards
802.3af and 802.3at Alternative B
PoE Max Power per Port (at PSE)
30 W
PoE Power Budget (at PSE)
120 W
Bandwidth (Non-blocking)
10 Gbps
Packer buffer
128 KB
MAC address table size
2K entries
Jumbo frame support
9216 bytes
Connector
4-pin industrial DC power socket
Input voltage range
7 – 57 VDC
PoE-out input voltage range
44 – 57 VDC
Power consumption
Idle: 2 W / Max (no PoE): 9 W / PoE Max: 129 W
Ethernet
5 x RJ45 ports, 10/100/1000 Mbps
Status LEDs
1 x Power LED, 10 x ETH status LEDs
Power
1 x 4-pin power connector
Other
1 x Grounding screw
Casing material
Full aluminum housing
Dimensions (W x H x D)
115 x 32 x 95 mm
Weight
350 g
Mounting options
DIN rail, wall mount, flat surface (all require additional kit)
Operating temperature
Operating humidity
Ingress Protection Rating
-40 °C to 75 °C
Regulatory
5% to 95% non-condensing
Standards
IP30
ESD
CE, UKCA, EAC, UCRF, CITC, ANRT, FCC, IC, NOM, Anatel, CB, E-mark
Radiated Immunity
EN 55032:2015EN 55035:2017EN 301 489-1 V2.2.3
EFT
EN 61000-4-2:2009
Surge Immunity (AC Mains Power Port)
EN IEC 61000-4-3:2006 + A1:2008 + A2:2010
CS
EN 61000-4-4:2012
DIP
EN 61000-4-5:2014
Standards
EN 61000-4-6:2014
The TSW100 Teltonika Industrial POE+ Ethernet Switch is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the TSW100 is commonly used:
Aerospace, Marine and Offshore, Medical and Healthcare, Military and Defence, Outdoor and Mobile Computing, Public Safety and Emergency Services, Transport and Logistics
These examples highlight the versatility of the TSW100 Teltonika Industrial POE+ Ethernet Switch across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Ethernet Switch fits your specific needs, please contact us.
The TSW100 Teltonika Industrial POE+ Ethernet Switch comes with a 24 Month Limited Warrany against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, TSW100 Teltonika Industrial POE+ Ethernet Switch, must be presented to RUGGED in the United Kingdom.
For more information about the TSW100 Teltonika Industrial POE+ Ethernet Switch or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the TSW100 Teltonika Industrial POE+ Ethernet Switch or require a custom solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Teltonika TSW100 or need a custom Ethernet Switch solution designed specifically for you, our team of technical experts are ready to assist you.
