DP-88 iKey Keyboard

The DP-88 is a small-footprint keyboard that meets harsh use standards. It has 88 full-size keys with embedded notebook key functions.

DP-88 Features

  • 88-Key Functionality
  • 12 Function Keys
  • Small Footprint
  • USB and PS2 Configurations Available
  • Various Keyboard and Language Layout Options

Manufacturer: iKey

Availabilty: Est. 5 - 10 Days

DP-88 Keyboard Options





The DP-88 is a small-footprint keyboard that meets harsh use standards. It has 88 full-size keys with embedded notebook key functions.

The DP-88 is a perfect fit for industrial, kiosk or mobile computing needs. The DP-88's small footprint and compact case allows for space saving and mobility, and a secondary legend can be accessed with a number lock key.

Specification
Manufacturer or Brand iKey
Mounting Format Desktop, Free Standing, Mobile, Vehicle Mount, VESA, VESA Mount
IP Rating IP66
Interface PS2, USB
Case Material ABS Polycarbonate
Housing Colour Black
Backlight No Backlight
Certifications IP Rated, NEMA 4X UL60950, FCC Part 15 Class B
Temperature Rating STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)
Humidity 100% Humidity Resistant
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Dimensions 11.40" x 6.30" x 1.86" (w-h-d) 289.56mm x 160.02mm x 47.24mm
Width (65 mm)
Height (37,5 mm)
Length (117 mm)
Warranty 1 Year Limited Warranty
Cable LENGTH: 4 ft coiled (1.2m)
Compatibility PS/2: All Windows Operating Systems USB: All Windows and Macintosh OS
Flammability PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO
Function Keys 12 Keys
Height (37,5 mm)
Key Feedback Tactile with Mechanical Snap
Key Material Industrial Silicone Rubber
Key Switch MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 in. (1.4 mm) ACTUATION FORCE: 7.05 oz +/- 1.06 oz (200g +/- 30g) FEEDBACK: Tactile with mechanical snap
Lifespan >10 Million Actuations
Mounting Filter Desktop
No. Of Keys 88
Pointing Device No Pointer
Power PS2: KEYBOARD: 50mA@5V (from Keyboard port) USB: 50mA@5V (from CPU port)
Product Weight 2 lbs +/- 0.10 lbs (0.91 kg +/- 0.05 kg)
Shock 3 x 11 ms Pulses of 50g on each of 3 Axes
Switch Force 200g (+/- 20g)
Switch / Key Travel 0.055 in (1.4mm)
Vibration POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
  • 88-Key Functionality
  • 12 Function Keys
  • Small Footprint
  • USB and PS2 Configurations Available
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request
The iKey DP-88 is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iKey DP-88 Keyboard are listed below:-

  • Factory Floor
  • Food Processing
  • Forklift Vehicle
  • Industrial Automation
  • Smart Factory
  • Warehousing
  • Industry 4.0

These are just some of the applications for the iKey DP-88 Keyboard The potential applications extend further than those shown above. For further information about the iKey DP-88 Keyboard or to check if the product is suitable for your application, please do not hesitate to contact us.
With our highly trained in house technical team and strong relationship with our manufacturers, we can offer numerous options and configurations for the iKey DP-88 Keyboard to suit your requirements. These options include:

  • Keyboard Layout
  • Keyboard Language
  • Cable Type
  • Cable Length
  • Interface

If your application requires unusual or individual modifications not listed above for the iKey DP-88 Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The iKey DP-88 Keyboard has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, iKey DP-88 Keyboard, must be presented to us here in the UK.
