IB897 iBASE Single Board Computer
IB897 IBASE Single Board Computer
IB897 Features
- Original OEM Module
- Rohs Compliant, CE
- Integrated Graphics DeviCE, Gma3650
- With DVI-D, 24-Bit Dual Channel Lvds and Crt Support
- 2X Gigabit Lan
The IB897 3.5-inch disk-size single board computer is based on the latest generation of Intel Atom processors. The IB897 integrates the 22nm quad-core Intel Atom E3845 processor that features 1.91GHz clock speed, 10-Watt power consumption, and a 2MB L2 cache. The board delivers much higher level of processing and graphics performance than previous generation Atom SBCs, while consuming minimal power consumption.
| Manufacturer or Brand | iBASE |
|---|---|
| Mounting Format | OEM |
| Form Factor | CPU Card |
| Processor | Intel |
| Certifications | RoHS Compliant, CE |
| Operating Temperature | -40C~85C (-40CF~185CF) |
| Storage Temperature | -40C~90C (-40CF~194CF) |
| Humidity | 90% Humidity Resistant (non-condensing @ 60C) |
| Dimensions | 102mm x 147mm (4" x 5.8") |
| Warranty | Standard Manufacturers Limited Warranty + Option to Extend |
| Ordering Info | B897-I45 Intel Atom E3845(1.91GHz) 3.5-inch Disk Size SBC w/ dual PCI-E GbE LAN, CRT, DisplayPort & LVDS (24-bit LVDS dual channel), mSATA, iSMART, Wide Temp. support IB897-I27 Intel Atom E3827(1.75GHz) 3.5-inch Disk Size SBC w/ dual PCI-E GbE LAN, CRT, DisplayPort & LVDS (24-bit LVDS dual channel), mSATA, iSMART, Wide Temp. support IB897-I15 Intel Atom E3815(1.46GHz) 3.5-inch Disk Size SBC w/ dual PCI-E GbE LAN, CRT, DisplayPort & LVDS (24-bit LVDS dual channel), mSATA, iSMART, Wide Temp. support IB897-I45P Intel Atom E3845(1.91GHz) 3.5-inch Disk Size SBC w/ dual PCI-E GbE LAN, CRT, DisplayPort & LVDS (24-bit LVDS dual channel), mSATA, iSMART, Wide Temp. support, pin-header type for power button and LED IB897-I27P Intel Atom E3827(1.75GHz) 3.5-inch Disk Size SBC w/ dual PCI-E GbE LAN, CRT, DisplayPort & LVDS (24-bit LVDS dual channel), mSATA, iSMART, Wide Temp. support, pin-header type for power button and LED HSIB897-BGA Heatsink for IB897 HSIB897-BGA-1 Heat spreader for IB897 IB76 Cable kit for IB897, w/ USB, COM, power, SATA + power, VGA |
| Audio | Intel Atom SoC built-in HD Audio controller + Realtek ALC269Q HD codec w/ class-D speaker amplifier |
| BIOS | AMI BIOS |
| Display Interface | Supports CRT, DisplayPort, and 24-bit dual channel LVDS |
| Expansion Slots | 2x Mini PCI-E (1x full-size, 1x half-size) |
| Form Factor FILTER | 3.5" SBC |
| H/W Monitor | Yes |
| I/O Chipset | Nuvoton NCT5523D 1x RS-232/422/485 (jumperless selection) 1x RS232, 2x SATA II |
| LAN Connector | 2x RJ-45 on board |
| LAN Controller | 2x Intel I210IT PCI-E Gigabit LAN |
| Others | Digital I/O, +9V~ +30V DC-In. iSMART, Wide temperature support |
| SSD | 1x mSATA, 1x Micro SD |
| System Memory | 2x DDR3L-1333 SO-DIMM, Max 8GB (Non-ECC) 1x DDR3L-1333 SO-DIMM, (IB897-215 only) |
| System Speed | 1.75GHz |
| USB | 1 port USB3.0 on board 1 port USB2.0 on board 2 ports USB2.0 via pin header |
| VGA Controller | Intel Atom SoC integrated Gen7 4EUs graphics |
| VGA Memory | Shared memory |
| Watchdog Timer | 256 levels |
- Original OEM Module
- Rohs Compliant, CE
- Integrated Graphics DeviCE, Gma3650
- With DVI-D, 24-Bit Dual Channel Lvds and Crt Support
- 2X Gigabit Lan
- 2X SATA Ii, 7X USB 2.0, 4X Com, 1X Cfast, Watchdog Timer
- Digital I/O, Isa High Drive, Mini PCI-E Socket
The iBASE IB897
is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iBASE IB897 Single Board Computer are listed below:-
These are just some of the applications for the iBASE IB897 Single Board Computer The potential applications extend further than those shown above. For further information about the iBASE IB897 Single Board Computer
or to check if the product is suitable for your application, please do not hesitate to contact us.
- Industrial Automation
- IOT
- Manufacturing Plant
- Smart Factory
- Industry 4.0
Currently there are no custom options listed for the iBASE IB897 Single Board Computer on our website.
If your application requires unusual or individual modifications for the iBASE IB897 Single Board Computer, please contact us with your exact requirements and we will help create a custom solution to meet your needs.
The iBASE IB897 Single Board Computer has a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)
To obtain service under this warranty, the warranty-eligible product, iBASE IB897 Single Board Computer, must be presented to us here in the UK.
