IK-SAM-AT iKey SnapON Tablet Keyboard

Snap-in-Place Fully Rugged Keyboard for Samsung Galaxy Tab Active2 Rugged Tablet

IK-SAM-AT Features

  • Designed to meet IP54 specifications
  • Integerated USB-C Charging Port for Tablet
  • Integrated pointing device with left and right mouse buttons
  • Designed to MIL-STD-810 High/Low Temperature Storage/Operation Constant
  • Designed to MIL-STD-810 High/Low Temperature Storage/Operation Cyclic




The IK-SAM-AT snap-on keyboard is designed exclusively for the Samsung Galaxy Tab Active2 Rugged Tablet. The keyboard is designed to meet military specifications and IP54 standards.

The keyboard easily snaps into place, provides an excellent typing experience and includes a USB-C Charging port for charging the tablet. The Galaxy Tab Active2 Tablet and iKey Keyboard is ideal for military and public safety settings, and other industries where the Samsung Tab Active2 Tablet is used.

The iKey IK-SAM-AT is availbie with Standard red backlighting or with Green, NVIS option.

Specification
Manufacturer or Brand iKey
Mounting Format ClipOn
IP Rating IP54
Interface Clip-On
Case Material ABS Polycarbonate
Housing Colour Black
Function Keys 12 Keys
Backlight Green, NVIS Green, Red
Certifications FCC/CE/IC
Operating Temperature -51C to +71C
Shock 26-Angle Drop @ 1.22 meters
Dimensions 10" x 6" x 1.125"
Warranty 1 Year Limited Warranty
Backlight Standard RED, Option NVIS, Green
Colour Black
Compatibility Galaxy Tab Active2 Tablet Only
Dimensions 10" x 6" x 1.125"
Function Keys 12 Keys
Key Material Industrial Silicone Rubber
No. Of Keys 82
Pointing Device Integrated FSR
Pointing Device Operating Principle Force Sensing Resistor
Power [email protected] MAX current draw from tablet
Product Weight 1.38 lb (without tablet)
Shock 26-Angle Drop @ 1.22 meters
Supply Current 250mA MAX current draw from tablet
Supply Voltage 5 Volts
Vibration 20-2kHz @ 7.7 Grms, 1-hour, 3 axes
  • Designed to meet IP54 specifications
  • Integerated USB-C Charging Port for Tablet
  • Integrated pointing device with left and right mouse buttons
  • Designed to MIL-STD-810 High/Low Temperature Storage/Operation Constant
  • Designed to MIL-STD-810 High/Low Temperature Storage/Operation Cyclic
  • Designed to MILSTD-810 Vibration & Mechanical Shock
  • Includes Samsung S pen holder
The iKey IK-SAM-AT is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iKey IK-SAM-AT Keyboard are listed below:-

  • Access Control
  • Accident and Emergency
  • Factory Floor
  • Field Service
  • Forklift Vehicle
  • In Vehicle
  • Manufacturing Plant
  • Military
  • Police Cars
  • Smart Factory
  • Warehousing
  • Industry 4.0

These are just some of the applications for the iKey IK-SAM-AT Keyboard The potential applications extend further than those shown above. For further information about the iKey IK-SAM-AT Keyboard or to check if the product is suitable for your application, please do not hesitate to contact us.
With our highly trained in house technical team and strong relationship with our manufacturers, we can offer numerous options and configurations for the iKey IK-SAM-AT Keyboard to suit your requirements. These options include:

  • Keyboard Layout
  • Keyboard Language
  • Backlight Colour
  • Custom Logo

If your application requires unusual or individual modifications not listed above for the iKey IK-SAM-AT Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The iKey IK-SAM-AT Keyboard has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, iKey IK-SAM-AT Keyboard, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
