RUGGED RD-3202PC-C2-OF 32″ Industrial Rugged Display

For teams working across aerospace, defence, and industrial console applications, the RUGGED RD-3202PC-C2-OF 32″ Industrial Rugged Display offers a reinforced and impact-resistant frame engineered for harsh conditions. Its dust-sealed and temperature-hardened design supports operation within 0°C to 50°C, making it suitable for demanding environments such as marine and industrial settings. The wide viewing angle LCD panel, with a brightness of 450 cd/m2 and 178-degree horizontal and vertical visibility, ensures clear readability in varied lighting conditions, enhancing operational awareness.

The display supports continuous duty with a backlight life of 50,000 hours and a fast response time under 6 ms, powered via a stable 24V DC input connector. Its CE and UL certifications verify compliance with rigorous industrial standards, contributing to reliability and long-term deployment viability. The RD-3202PC-C2-OF measures 793.5 x 520.9 x 123.5 mm, balancing sizeable active display area with robust protection suited for industrial-grade tasks that require consistent performance.

RD-3202PC-C2-OF Features

  • 32" Display
  • Open Frame Display

Request a Quote

Manufacturer

Certifications & Standards

Ruggedness

Mounting Format

Screen Size

Country Of Manufacture

Taiwan

Certifications

CE, UL

Dimensions

793.5 (L) x 520.9 (W) x 123.5 (D) mm

Display Accessories Included

AC/DC Power Adapter

Active Display Area

697.69 (H) x 392.26 (V)

Aspect Ratio

0.672916667

Backlight Life

50,000 hours (typ)

Contrast Ratio

83.33402778

Display Brightness

450 cd/m2

Display Resolution

1366 x 768

Input Power

Power Input: 24V DC-IN (4-Din connector)

Osd Control

No

Pixel Dimension

0.511 (H) x 0.511 (V) mm

Power Consumption

Operation: 190W (typ)

Response Time

< 6 ms (G-to_G)

Screen Technology

LCD

Screensize

32"

Viewing Angle

178 degree in horizontal & 178 in vertical (typ)

Operating Temperature

OPERATING: 0C to +50C

Storage Temperature

STOREAGE: -20C to +60C

Temperature Rating

OPERATING: 0C to +50C / STOREAGE: -20C to +60C

The RUGGED RD-3202PC-C2-OF 32″ Industrial Rugged Display is designed and engineered for use in demanding environments where reliability, durability are essential. The RD-3202PC-C2-OF supports a wide range of industries and operational applications.

Common deployment industries include: Aerospace, Broadcast and Media, Defence And Military, Energy and Utilities, Industrial Manufacturing, Marine And Offshore.

Across these sectors, the RD-3202PC-C2-OF is typically used in applications such as Aircraft Cockpit And Avionics Support Systems, Industrial HMI And Machine Interfacing, Marine Bridge And Vessel Control Systems, Medical Carts And Clinical Mobile Workstations, Process Control And Shop-Floor Monitoring, Robotics And Autonomous System Control, SCADA And Control-Room Access, Secure Communications And Command-And-Control.

These examples demonstrate the versatility of the RD-3202PC-C2-OF across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the RD-3202PC-C2-OF is appropriate for your specific application, please contact us.

The RUGGED RD-3202PC-C2-OF 32″ Industrial Rugged Display comes with a 1 Year RTB UK Warranty With Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, RUGGED RD-3202PC-C2-OF 32″ Industrial Rugged Display, must be presented to RUGGED in the United Kingdom.

For more information about the RUGGED RD-3202PC-C2-OF 32″ Industrial Rugged Display or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Request further details about the RUGGED RD-3202PC-C2-OF 32″ Industrial Rugged Display

If you have any questions about the RUGGED RD-3202PC-C2-OF please get in touch today, our team of technical experts are ready to assist you.
