RKB-B255TP USB RKB-B255TP PS2 RKB-B255TP IP65-RATED RKB-B255TP TOUCHPAD RKB-B255TP CUSTOMISABLE


RKB-B255-TB-FN-1 RUGGED Keyboard

RKB-B255-TB-FN-1 RUGGED Keyboard

RKB-B255TP-1 RUGGED Keyboard

RKB-B255TP-1 RUGGED Keyboard

RKB-B255TP RUGGED Keyboard

MINI 68 keys IP65 dynamic compact format vandal proof stainless steel industrial keyboard with sealed touchpad for fast and accurate cursor position with extremely smooth operation

RKB-B255TP Features

  • Compact Panel Mounted Metal Keyboard
  • Rugged Construction
  • Can Be Customised / Modified
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

RKB-B255TP Keyboard Options



MINI 68 keys IP65 dynamic compact format vandal proof stainless steel industrial keyboard with sealed touchpad for fast and accurate cursor position with extremely smooth operation without any noise, 3 mouse buttons designed for right & left clicking and scrolling up and down with ball rolling, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input, rear panel mounting.

Specification
Manufacturer or Brand RUGGED
Mounting Format Panel Mount
IP Rating IP65
Interface PS2, USB
Case Material Stainless Steel
Housing Colour Stainless Steel
Certifications RoHS Compliant, CE
Operating Temperature Operating temperature:-20C to +60C
Storage Temperature Storage temperature: -30C to +70C
Temperature Rating STORAGE: -30C to +70C OPERATING: -20C to +60C
Humidity 30-90% Humidity Resistant
Dimensions 255.0mm x 90.0mm (front panel), 275.0mm x 102.80m (back panel)
Width 105.0mm
Length 255.0mm
Warranty 1 Year Limited Warranty
Ball Material stainless steel
Compatibility All windows, Linux, Unix, Mac OSX
Dimension with Trackball 255.0mm x 105.0mm (top panel) , 275.0mm x 117.80mm (rear panel)
EMC Compliance with the council IEC 61000-4-2:2008?IEC 61000-4-3:2006+AI:2007+A2:2010?IEC 61000-4-4:2004
EMI EN 55022: 2010
EMS EN 55024:2010
Frontplate Material 1.5mm Thickness Super Quality Brushed Stainless Steel
Key Material Metal
Key Spacing 10.0mm x 10.0mm for normal keys, 10.0mm x 20.0mm for enter key, 10.0mm x 75.0mm for space bar.
Key Switch Gold-on-Gold key Switch Technology
Lifespan > 5 Million Actuations
Material (Bottom Plate) 3.0mm Thickness Brushed & Oxidized Aluminium
Mounting Filter Panel Mount
MTBF >50000H
MTTR <30min
No. Of Keys 68
Operating Force 1.50N+/-0.1N
Pointing Device Touchpad
Power +5V DC +/-5%ï¾  appr. 30mAï¾
Product Weight 1.00KGs
Resolution +400 DPI
Supply Current appr. 30mA
Supply Voltage +5V DC +/-5%
Switch / Key Travel 0.45mm
Trackball Diameter 25mm
  • Compact Panel Mounted Metal Keyboard
  • Rugged Construction
  • Can Be Customised / Modified
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request
The RUGGED RKB-B255TP is used in a wide range of industries for a broad range of rugged applications. The most common applications for the RUGGED RKB-B255TP Keyboard are listed below:-

  • Factory Floor
  • Industrial Automation
  • Kiosk and Self-Service
  • Manufacturing Plant
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the RUGGED RKB-B255TP Keyboard The potential applications extend further than those shown above. For further information about the RUGGED RKB-B255TP Keyboard or to check if the product is suitable for your application, please do not hesitate to contact us.
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the RUGGED RKB-B255TP Keyboard to suit your requirements. These options include:

  • Keyboard Layout
  • Keyboard Language
  • Cable Type
  • Cable Length
  • Interface

If your application requires unusual or individual modifications not listed above for the RUGGED RKB-B255TP Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The RUGGED RKB-B255TP Keyboard has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, RUGGED RKB-B255TP Keyboard, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
