SK-102-M-FSR iKey Keyboard
iKey SK-102-M keyboard provides full-size versatility in a rugged, compact design, with the added convenience of an integrated Force Sensing Resistor.
SK-102-M-FSR Features
- Rugged, Compact Design
- Integrated Force Sensing Resistor
- Ms Windows Function Keys
- USB and PS2 Configurations Available
- Various Keyboard and Language Layout Options
iKey’s SlimKey™ SK-102-M keyboard provides full-size versatility in a rugged, compact design, with the added convenience of an integrated Force Sensing Resistor.
The SlimKey™ SK-102-M is engineered to meet NEMA 4X specifications and is ideal for use in industrial, medical and material handling applications. The large numeric pad on the SK-102-M allows for easy data entry, while the robust polycarbonate case is durable in the roughest of environments.
The SlimKey™ SK-102-M is engineered to meet NEMA 4X specifications and is ideal for use in industrial, medical and material handling applications. The large numeric pad on the SK-102-M allows for easy data entry, while the robust polycarbonate case is durable in the roughest of environments.
| Manufacturer or Brand | iKey |
|---|---|
| Mounting Format | Desktop, Free Standing, Mobile, Vehicle Mount, VESA, VESA Mount |
| IP Rating | IP66 |
| Interface | PS2, USB |
| Case Material | ABS Polycarbonate |
| Housing Colour | Black |
| Backlight | No Backlight |
| Certifications | IP Rated, NEMA 4X UL60950, FCC Part 15 Class B |
| Temperature Rating | STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F) |
| Humidity | 100% Humidity Resistant |
| Shock | 3 x 11 ms Pulses of 50g on each of 3 Axes |
| Dimensions | 14.50" x 5.50" x 1.56" (w-h-d) 368.3mm x 139.7mm x 39.6mm |
| Warranty | 1 Year Limited Warranty |
| Cable | Single-Cable USB |
| Compatibility | All Windows and Macintosh Operating Systems |
| Flammability | PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO |
| Function Keys | 12 Keys |
| Key Feedback | Tactile with Mechanical Snap |
| Key Material | Industrial Silicone Rubber |
| Key Switch | MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.05 oz +/- 1.06 oz (200g +/- 30g) FEEDBACK: Tactile with mechanical snap |
| Lifespan | >10 Million Actuations |
| Mounting Filter | Desktop |
| No. Of Keys | 102 |
| Pointing Device | Force Sensing Resistor |
| Power | PS/2: KEYBOARD: 50mA@5V (from Keyboard port) HULAPOINT: 35mA@5V (from Mouse port) USB: 85mA@5V (from CPU port) |
| Product Weight | 2 lbs +/- 0.10 lbs (0.91 kg +/- 0.05 kg) |
| Shock | 3 x 11 ms Pulses of 50g on each of 3 Axes |
| Switch Force | 200g (+/- 30g) |
| Switch / Key Travel | 0.055 in (1.4mm) |
| Vibration | POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours |
- Rugged, Compact Design
- Integrated Force Sensing Resistor
- Ms Windows Function Keys
- USB and PS2 Configurations Available
- Various Keyboard and Language Layout Options
- Customisation Available On Request
The iKey SK-102-M-FSR
is used in a wide range of industries for a broad range of rugged applications. The most common applications for the iKey SK-102-M-FSR Keyboard are listed below:-
These are just some of the applications for the iKey SK-102-M-FSR Keyboard The potential applications extend further than those shown above. For further information about the iKey SK-102-M-FSR Keyboard
or to check if the product is suitable for your application, please do not hesitate to contact us.
- Accident and Emergency
- Clinical Engineering
- Dental Surgeries
- Factory Floor
- Food Processing
- Helicopter Consoles
- Hospitals
- Industrial Automation
- Infection Control
- Marine Consoles
- Medical Carts
- Pharmacy
- Radiology
- Smart Factory
- Theatres
- Veterinary Hospitals
- Ward Areas
- Doctors Surgeries
- Industry 4.0
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the iKey SK-102-M-FSR Keyboard to suit your requirements. These options include:
If your application requires unusual or individual modifications not listed above for the iKey SK-102-M-FSR Keyboard, please contact us with your exact requirements and we will help create a custom solution to meet your needs.
- Keyboard Layout
- Keyboard Language
- Cable Type
- Cable Length
- Interface
The iKey SK-102-M-FSR Keyboard has a 1 Year Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)
To obtain service under this warranty, the warranty-eligible product, iKey SK-102-M-FSR Keyboard, must be presented to us here in the UK.
For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
