iKey SK-102-461-M-FSR Military Grade Rugged Keyboard

Designed for military and industrial field use, the iKey SK-102-461-M-FSR Military Grade Rugged Keyboard provides reliable input in EMI-prone environments. It features a vibration-tolerant and EMI-resistant design compliant with MIL-STD-461-G and MIL-STD-810G standards for shock and vibration resistance. The fully sealed NEMA 4X ABS polycarbonate housing ensures dust and weather protection, supporting continuous-duty deployment in harsh conditions.

Industrial silicone rubber keys offer tactile feedback with mechanical snap and durability rated for over 10 million actuations. Operating across temperatures from -40°C to +70°C and with 100% humidity resistance, this keyboard integrates a Force Sensing Resistor pointing device and supports USB and PS/2 connectivity, making it compatible with various Windows and Macintosh systems. Multiple mounting options enhance flexibility in different vehicle, aerospace, or heavy industrial deployments.

SK-102-461-M-FSR Features

  • Designed To Meet MIL-STD-461
  • Integrated Force Sensing Resistor
  • Mobile Mounting Case
  • USB and PS2 Configurations Available
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

IP Rating

Manufacturer

Country Of Manufacture

United States

Backlight

No Backlight

Case Material

ABS Polycarbonate

Certifications

NEMA 4X UL60950, FCC Part 15 Class B

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

14.60" x 5.55" x 1.05" (w-h-d) 370.8mm x 141mm x 26.7mm

Extended Warranty

Available On Request

Housing Colour

Black

Humidity

100% Humidity Resistant

Cable

Single-Cable USB

Compatibility

All Windows and Macintosh Operating Systems

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.05 oz +/- 1.06 oz (200g +/- 30g) FEEDBACK: Tactile with mechanical snap

Lifespan

>10 Million Actuations

No. Of Keys

102

Pointing Device

Force Sensing Resistor

Power

PS/2: KEYBOARD: 50mA@5V (from Keyboard port) HULAPOINT: 35mA@5V (from Mouse port) USB: 85mA@5V (from CPU port)

Product Weight

1.50 lbs +/- 0.10 lbs (0.68 kg +/- 0.05kg)

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

200g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)

The iKey SK-102-461-M-FSR Military Grade Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The SK-102-461-M-FSR supports a wide range of industries and operational applications.

Common deployment industries include: Aerospace, Defence And Military, Emergency Services, Energy and Utilities, Industrial Manufacturing, Marine And Offshore, Oil and Gas, Security And Surveillance.

Across these sectors, the SK-102-461-M-FSR is typically used in applications such as Industrial HMI And Machine Interfacing, Mobile Workforce Operations, Process Control And Shop-Floor Monitoring, Secure Access, Authentication, And Control Terminals, Vehicle-Mounted Computing (MDTs / VMCs).

These examples demonstrate the versatility of the SK-102-461-M-FSR across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the SK-102-461-M-FSR is appropriate for your specific application, please contact us.

The iKey SK-102-461-M-FSR Military Grade Rugged Keyboard comes with a 3 Years Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey SK-102-461-M-FSR Military Grade Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey SK-102-461-M-FSR Military Grade Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey SK-102-461-M-FSR Military Grade Rugged Keyboard or require a custom solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iKey SK-102-461-M-FSR or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
