Digi Connect EZ 4I Industrial Rated Serial Server, 4-port with LTE + WI-FI & Accessories – EZ04-IAG4-EXT
Click-to-connect | Modern, secure serial connectivity that boots in seconds, configures in minutes and runs for years.
Most companies are not replacing their equipment, they are updating the way they talk to it. Digi Connect EZ modernizes operational infrastructure with expanded network connectivity and functionality for today’s applications. It is designed to meet the demands of a wide range of critical serial applications including connecting to automation, robotics control, centralized device management, data acquisition and point-of-sale equipment.
Digi Connect EZ is a click-to-connect solution with 1, 2 or 4 serial ports, software-selectable for RS-232/422/485 communication, as well as optional LTE, Wi-Fi and industrial specifications (C1D2). It takes only a few minutes to configure with intelligent, use case-based options so that you can quickly install without having to modify your equipment or applications.
Digi simplifies key security requirements for critical infrastructure and distributed systems with enhanced access control, management and configuration capabilities. Digi Connect EZ and built-in Digi TrustFence give your security and operations teams peace of mind against evolving security threats with encrypted connections, centralized authentication, VPN support and scalable security updates.
Digi Connect EZ supports the widest range of industry-standard and device-specific protocols using serial tunnelling, TCP/UDP connections or Digi’s patented RealPort COM port redirector for remote native COM port access. A built-in Python environment enables application development and customization at the device level, including event-based programmability, data conversion and full control of device connections.
EZ04-IAG4-EXT Features
- 4-Port With LTE & Wi-Fi
- Industrial certification: Class 1, Division 2
- Connect a wide variety of serial equipment over IP networks
- 10/100/1000 Ethernet (auto-sensing)
- Built-in Digi TrustFence for device security, secure encrypted connections, ongoing monitoring and support
- Easy setup and mass configuration with Digi Navigator and Digi Remote Manager
Request for Quote (RFQ)
Product Type
Format
Manufacturer
Country Of Manufacture
United States
Approvals / Certifications
Environmental: ROH53, Safety: IEC62368-1, CB, EN62311, Industrial certification: Class 1, Division 2
Box Content
Digi Connect EZ 4i - serial server, 4-port, industrial-rated, with LTE, Wi-Fi and accessories Digi CORE plug-in LTE modem (1002-CMG4-GLB) Antenna - dipole, 4G, quantity 2 (76002118) Antenna - 2.4 and 5 GHz (29000938) Power supply - 12 V, 2.5 A (76002079) DIN rail clip (76002095)
Case Material
Metal
Cellular Connectors
Antenna connectors: (2) 50 SMA (center pin: female)
Custom Options Products
Cable Length,Connections,Laser Etching,Custom Printing,Power Supply,Mounting Options
Dimensions
(L x W x H): 19.2 x 13.4 x 3.5 cm (7.56 x 5.28 x 1.38 in)
Emissions / Immunity
CE; RED; FCC Part 15, Subpart B; ICES-003; AU/NZS CISPR32
Ethernet
Ports: (2) RJ-45; 10/100/1000 Mbps (auto-sensing)
Housing Colour
Black
Humidity
5% to 95% (non-condensing)
Local Management
Digi Navigator discovery and configuration tool, Web UI (HTTP/HTTPS); CLI (Telnet, SSH)
LTE (G4)
LTE Cat 4: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B38, B40, B41, 3G: B1, B2, B4, B5, B6, B8, B19, 2G EDGE / GPRS: 850 / 900 / 1800 / 1900 MHz
Management/Troubleshooting Tools
Digi Navigator discovery and configuration tool, FTP client, SCP, protocol analyzer with PCAP for Wireshark, event logging with syslog and SMTP client, NTP/SNTP, Nagios, Intelliflow, iPerf, Dynamic DNS, ping, traceroute
Memory
256 MB RAM, 4 GB Flash
Serial I/O
Ports: (4) RJ45-10; RS-232 DTE/RS-422/RS-485 capable, software selectable RS-232 / EIA-232 Serial Modes: Signal support TXD, RXD, RTS, CTS, DTR, DSR, DCD, RI flow control options: XON/OFF, CTS/RTS, RTS-toggle RS-422 / EIA-422 Serial Modes: TX+/-, RX+/-, software termination, pre-delay/post-delay RS-485 / EIA-485 Serial Modes: Data+/Data-, software termination, pre-delay/post-delay
Operating Temperature
Standard operating temperature of Connect EZ device: 0 degrees celsius to 40 degrees celsius - With Digi CORE plug-in LTE modem: 0 degrees celsius to 40 degrees celsius
Ordering Info
EZ04-IAG4-EXT - Includes Digi CORE plug-in LTE modem, 4G dipole antenna, 2.4 and 5 GHz antenna, power supply and DIN rail clip (DIN rail bracket available separately - 76002093)
Power Consumption
9 V @ 1.5 A max, 5 W typical with Digi CORE modem, 4.5 W typical without Digi CORE modem
Power Input
Phoenix connector: 9 - 30 VDC, Connector: 2-position rewireable plug with securing screws included
Protocols
Authentication: TACACS+, LDAP, Enterprise RADIUS
Remote Management
Digi Remote Manager, SNMP v3 (user installed/managed)
SIM Security
Secured in cellular module
SIM Slots
(2) Mini-SIM (2FF)
Status LED
Each Ethernet and serial port has two status LEDs; power, signal, LTE, Wi-Fi, Ethernet, serial
WI-FI Access Points
Maximum 2 access points (access point mode: regardless of combination of clients and access points)
WI-FI Clients
Maximum 10 clients (access point mode: regardless of combination of clients and access points)
WI-FI Connectors
(1) 50 SMA (center pin: male)
WI-FI Modes
Client mode and access point mode simultaneously
WI-FI Module
1 x 1 SISO dual-band 802.11a/b/g/n/ac (2.4 GHz / 5 GHz)
WI-FI Security
WPA-3/WPA-2 personal, WPA/WPA-2 enterprise
The Digi Connect EZ 4I Industrial Rated Serial Server, 4-port with LTE + WI-FI & Accessories – EZ04-IAG4-EXT is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the EZ04-IAG4-EXT is commonly used:
Aerospace, Industrial and Manufacturing, Marine and Offshore, Medical and Healthcare, Military and Defence, Outdoor and Mobile Computing, Pharmaceutical, Public Safety and Emergency Services, Transport and Logistics
These examples highlight the versatility of the Digi Connect EZ 4I Industrial Rated Serial Server, 4-port with LTE + WI-FI & Accessories – EZ04-IAG4-EXT across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Serial Server fits your specific needs, please contact us.
The Digi Connect EZ 4I Industrial Rated Serial Server, 4-port with LTE + WI-FI & Accessories – EZ04-IAG4-EXT comes with a 5-year for base Connect EZ device, 3-year for Digi CORE plug-in LTE modem Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Digi Connect EZ 4I Industrial Rated Serial Server, 4-port with LTE + WI-FI & Accessories – EZ04-IAG4-EXT, must be presented to RUGGED in the United Kingdom.
For more information about the Digi Connect EZ 4I Industrial Rated Serial Server, 4-port with LTE + WI-FI & Accessories – EZ04-IAG4-EXT or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Digi Connect EZ 4I Industrial Rated Serial Server, 4-port with LTE + WI-FI & Accessories – EZ04-IAG4-EXT or require a custom solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Digi International EZ04-IAG4-EXT or need a custom Serial Server solution designed specifically for you, our team of technical experts are ready to assist you.
