E50-Panel-Halo IP68-RATED E50-Panel-Halo USB E50-Panel-Halo PS2 E50-Panel-Halo OEM E50-Panel-Halo SSD E50-Panel-Halo LED

E50-Panel Cursor Controls Trackball

E50-Panel Cursor Controls Trackball

F3053 Cursor Controls Trackball

F3053 Cursor Controls Trackball

E50-Panel-Halo Cursor Controls Trackball

The E50 Panel Backlit (Halo) module is an extremely high specification trackball device that incorporates the latest Cursor Controls Ltd IP68 technology, making it the ideal for use in the most demanding of environments.

E50-Panel-Halo Features

  • Halo Illumination On The Ball and Switches
  • Solid State Optical Trackball
  • Integrated Hall-Effect Scroll Wheel
  • Integrated Left, Middle and Right Switch Functionality
  • Sealing Up To IP68

Manufacturer: Cursor Controls

E50-Panel-Halo Trackball Options




The E50 Panel (Halo & Backlit Buttons) module is an extremely high specification trackball device that incorporates the latest Cursor Controls Ltd IP68 technology, making it the ideal for use in the most demanding of environments. The module combines the patented optical trackball with the new Cursor Controls Ltd hall-effect scroll wheel. To compliment these two technologies the module also includes left, middle and right switch functionality found in conventional desktop trackballs/mice making the E50 Series module a complete human interface solution for control of a cursor. The E50 trackball is available with a variety of electrical outputs, tracking force options, and sealing capabilities up to IP68. The solid state design allows the device to be subjected to extreme conditions and provides the user with the ability to wash down, decontaminate, and sterilise, making it the ideal trackball for a wide range of demanding applications and environments. The  E50 Panel Halo & Backlit Buttons unit has been designed to be back of panel mounted as part of OEM keyboards and consoles.
Specification
Manufacturer or Brand Cursor Controls
Mounting Format Panel Mount
Interface PS2, USB
Case Material ABS Polycarbonate
Housing Colour Black
Certifications CE, RoHS compliant
Humidity 100% Humidity Resistant (when properly installed)
Warranty 18 Month Limited Warranty
Interface Filter USB & PS2 (Auto Select)
Mounting Filter Rear Mount
  • Halo Illumination On The Ball and Switches
  • Solid State Optical Trackball
  • Integrated Hall-Effect Scroll Wheel
  • Integrated Left, Middle and Right Switch Functionality
  • Sealing Up To IP68
  • Smooth Operation In Rugged Environments
  • Various Colours Available
The Cursor Controls E50-Panel-Halo is used in a wide range of industries for a broad range of rugged applications. The most common applications for the Cursor Controls E50-Panel-Halo Trackball are listed below:-

  • Broadcast Consoles
  • Factory Floor
  • Industrial Automation
  • Marine Consoles
  • Miltary Consoles
  • Smart Factory
  • Industry 4.0

These are just some of the applications for the Cursor Controls E50-Panel-Halo Trackball The potential applications extend further than those shown above. For further information about the Cursor Controls E50-Panel-Halo Trackball or to check if the product is suitable for your application, please do not hesitate to contact us.
With our highly trained in house technical team and strong relationship with our manufacturers, we can offer numerous options and configurations for the Cursor Controls E50-Panel-Halo Trackball to suit your requirements. These options include:

  • Cable Type
  • Cable Length
  • Interface
  • Trackball Colour
  • Backlight Colour

If your application requires unusual or individual modifications not listed above for the Cursor Controls E50-Panel-Halo Trackball, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The Cursor Controls E50-Panel-Halo Trackball has a 18 Month Limited Warranty against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, Cursor Controls E50-Panel-Halo Trackball, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
