Rextorm PM-521 10.1" Fully Rugged Windows / Android Tablet. Perfectly balanced performance, yet competitive pricing. The PM-521 offers an unparalleled operating experience and cost-effective option.

PM-521 Features

  • Intel Atom Processor E3827 1.75GHz
  • IP65, MIL-STD-810G, 5 Feet Drop Resistance
  • 1000 Nit Sunlight Readable Display
  • Capacitive Touch Supports Glove Touch, Water Rejection, Palm Rejection, 2mm Hard Tip Stylus; Digitizer By Request
  • GNSS, Wi-Fi, Bluetooth and Optional 4G LTE


PM-521 IP65-RATED PM-521 CAMERA PM-521 USB PM-521 MIL-STD-810G PM-521 BARCODE-READER PM-521 WINDOWS-OS PM-521 BLUETOOTH PM-521 RFID
Rextorm PM-521 10.1ヤ Fully Rugged Windows / Android Tablet. Perfectly balanced performance, yet competitive pricing. The PM-521 offers an unparalleled operating experience and cost-effective option.

Specification
Manufacturer or Brand RuggON
Mounting Format Car Mount, Mobile, Vehicle Mount
Screen Size 10.1"
Processor Intel
Certifications CE, RoHS compliant
Warranty Standard Manufacturers Limited Warranty + Option to Extend
Camera Front : 2MP Rear : 5MP with auto focus and LED flash
Data Capture NFC (option) 2D barcode reader (option) Smart card reader - CAC (snap-on, by request) Magnetic stripe reader (snap-on, by request)
Display 10.1-inch 1920 x 1200 WUXGA; 1000 nit sunlight readable 10-point capacitive touch supports glove touch, water rejection, palm rejection, 2mm hard tip stylus Gorilla Glass3 Digitizer by request
Integrated Communications 802.11 a/b/g/n/ac Bluetooth V4.0 GNSS (GPS/GLONASS/BeiDou) Optional 3.5G or 4G LTE
I/O Interfaces USB 3.0 type A x 1, USB 2.0 type A x 1 Gigabit Ethernet (RJ-45 ) x 1 RS-232 x 1 Micro SD slot x 1, Micro SIM slot x 1, Micro HDMI x 1 Audio jack (headphone/microphone combo) x 1 Speaker & microphone Dual RF pass-through connector for WLAN, GNSS, WWAN 12-p
Operating System Windows Embedded 8.1 Industry 64-bit Windows Embedded 8 Standard 64-bit Windows 7 Professional 64-bit Windows Embedded Standard 7 64-bit Android 4.4 (by request)
Power External AC Power Adapter
Processor, Chipset Intel Atom processor E3827 1.75GHz 4GB DDR3L (8GB by request) 120GB mSATA SSD (option 240GB)
Ruggedness/Durability Shock & vibration : MIL-STD-810G Drop : 5 feet drop IP65 resistant design Operating temperature : -20 C to +50 C
Security TPM1.2
  • Intel Atom Processor E3827 1.75GHz
  • IP65, MIL-STD-810G, 5 Feet Drop Resistance
  • 1000 Nit Sunlight Readable Display
  • Capacitive Touch Supports Glove Touch, Water Rejection, Palm Rejection, 2mm Hard Tip Stylus; Digitizer By Request
  • GNSS, Wi-Fi, Bluetooth and Optional 4G LTE
  • Hot Swappable Battery Design
  • Wide Expansion Design For Data Capture
  • Dual Pass-Through Connector For Wlan, GNSS, WWAN
The RuggON PM-521 is used in a wide range of industries for a broad range of rugged applications. The most common applications for the RuggON PM-521 Tablet are listed below:-

  • Factory Floor
  • Field Service
  • Mobile Worker

These are just some of the applications for the RuggON PM-521 Tablet The potential applications extend further than those shown above. For further information about the RuggON PM-521 Tablet or to check if the product is suitable for your application, please do not hesitate to contact us.
We take pride in our highly skilled in-house technical team and our strong relationships with manufacturers. Together, we are well-equipped to provide you with an array of options and configurations for the RuggON PM-521 Tablet to suit your requirements. These options include:

  • Interface
  • Processor
  • Memory
  • Storage
  • Connections
  • Operating System

If your application requires unusual or individual modifications not listed above for the RuggON PM-521 Tablet, please contact us with your exact requirements and we will help create a custom solution to meet your needs.

The RuggON PM-521 Tablet has a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials from the date of shipment, (unless otherwise agreed in writing)

To obtain service under this warranty, the warranty-eligible product, RuggON PM-521 Tablet, must be presented to us here in the UK.

For further information on the above or for repairs and service outside the the scope of warranty, please visit the warranty section of our webiste.
