RUGGED RKB-8635G-B Black Panel Mount Stainless Steel Industrial Rugged Keyboard

For teams working across industrial settings, the RUGGED RKB-8635G-B Black Panel Mount Stainless Steel Industrial Rugged Keyboard offers a sealed, robust solution for demanding environments. Made from industrial-grade stainless steel, the keyboard provides corrosion resistance and dust sealing with an IP65 rating, making it suitable for applications exposed to moisture and contaminants. It features USB or PS2 connectivity options and supports multiple keyboard layouts, enabling easy integration into varied operational contexts.

This rugged keyboard is engineered for continuous-duty use, enduring vibrations within industrial frequencies and functioning reliably between -40°C and +70°C. Its carbon contact technology supports over 10 million keystrokes, ensuring a long operational lifespan in harsh conditions. The panel mount design measures 329.8mm by 99.8mm, and the aluminium alloy base plate adds structural strength. Compatible across major operating systems including Windows, Linux, and Mac, the RKB-8635G-B combines durability with practical versatility for industrial deployments.

RKB-8635G-B Features

  • Industrial Grade Stainless Steel
  • IP65 Rated
  • Rear Panel Mount
  • Suitable for Industrial & Public Environments
  • Various Keyboard and Language Layout Options
  • UK RTB Warranty

Request a Quote

IP Rating

Operating System

Manufacturer

Country Of Manufacture

China

Case Material

Stainless Steel

Certifications

CE, FCC, RoHS Compliant

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

329.8mm x 99.8mm (front panel)

Extended Warranty

Available On Request

Housing Colour

Stainless Steel

Base plate Material

Aluminum Alloy

Case Material

Stainless Steel (front panel) and Aluminum Alloy

Certified European Standards

CE, FCC, RoHS Compliant

Colour

Black

Compatibility

DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/7,8,10 Linux, Mac,etc

Connectivity

USB or PS2 (optional)

Dimensions

329.8mm*99.8mm (front panel)

Frontplate Material

Industrial Grade Stainless Steel

Function Keys

12

Key Switch

Carbon Contact Technology

Lifespan

>10 Million Actuations

Material (Bottom Plate)

Aluminum Alloy

MTBF

>50000H

MTTR

<30min

No. Of Keys

68

Supply Voltage

+5V DC +/-5%

Switch / Key Travel

1.5mm

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Lifetime

Lifespan > 5 years

Operating System

IOS,Linux,Windows,Windows 10 IOT

Operating Temperature

OPERATING: -40C to +70C (-40F to +158F)

Storage Temperature

STORAGE: -50C to +80C

The RUGGED RKB-8635G-B Black Panel Mount Stainless Steel Industrial Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The RKB-8635G-B supports a wide range of industries and operational applications.

Common deployment industries include: Construction, Energy and Utilities, Food And Beverage Processing, Industrial Manufacturing, Logistics And Supply Chain, Public Sector, Rail And Transport, Security And Surveillance.

Across these sectors, the RKB-8635G-B is typically used in applications such as ATEX And Hazardous-Area Data Capture, Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, SCADA And Control-Room Access.

These examples demonstrate the versatility of the RKB-8635G-B across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the RKB-8635G-B is appropriate for your specific application, please contact us.

The RUGGED RKB-8635G-B Black Panel Mount Stainless Steel Industrial Rugged Keyboard comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, RUGGED RKB-8635G-B Black Panel Mount Stainless Steel Industrial Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the RUGGED RKB-8635G-B Black Panel Mount Stainless Steel Industrial Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the RUGGED RKB-8635G-B Black Panel Mount Stainless Steel Industrial Rugged Keyboard or require a custom solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the RUGGED RKB-8635G-B or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.

  • Alternative Products

    Discover a range of alternatives that offer comparable features and quality to the product you’re viewing.

    Our selection of similar items provides diverse options, allowing you to explore different designs, functionalities, and styles tailored to your preferences. Each product has been carefully chosen to ensure it meets the high standards you expect, enabling you to make a well-informed decision based on your unique requirements.

    Browse through our related products and find the perfect match that complements your choice seamlessly.

    • Sealed IP65 stainless steel construction
    • Over 10 million keystroke lifespan
    • USB and PS2 connectivity options
    • Wide operating temperature range -40°C to +70°C
    • IP66 dust and liquid sealed membrane
    • Integrated IP65-sealed touchpad
    • Reinforced aluminium and polycarbonate case
    • Certified IEC 61000 EMC and RoHS CE FCC
    • Industrial-grade stainless steel construction
    • IP65 sealed against dust and water
    • Wide operating temperature range -40°C to +70°C
    • Compatible with USB and PS/2 systems
    • Industrial-grade stainless steel
    • IP65 dust and water protection
    • Over 10 million key actuations
    • Integrated touchpad for efficient input
  • Having trouble finding what you're looking for?


    Selecting the right product for your specific application and environment can be quite challenging. At Rugged, our team of experts is on hand to assist you in making the best choice. Whether you have questions about product specifications or require guidance through our range of solutions, we’re here to help.

    With our extensive industry knowledge and commitment to quality, we can ensure you find the ideal solution tailored to your needs.

    Contact Us
  • Frequently Asked Questions

    All Rugged Limited industrial keyboards are engineered for seamless operation, even when wearing gloves. This crucial feature ensures that users can maintain productivity and safety in environments where glove use is mandatory, such as industrial settings, cleanrooms, or outdoor work.

    Our commitment to robust design means every Rugged Keyboard offers responsive feedback and accurate input, regardless of whether you’re using thin surgical gloves or heavy-duty work gloves. This makes our solutions ideal for a wide range of applications where standard keyboards would be impractical.

    Rugged Limited specialises in providing industrial peripherals that are engineered to withstand harsh conditions, making a rugged keyboard an ideal companion for industrial PCs. These keyboards are built to offer durability and consistent functionality in environments where standard office equipment would quickly fail.

    Our rugged keyboards are developed for high compatibility and robust performance, ensuring they can stand up to the demands of various industrial settings. They are designed to prevent contamination from dust, dirt, and liquids, which are common in many industrial applications. Some models also feature backlight options, crucial for low-light conditions often found in industrial environments, and integrated pointing devices to streamline operations.

    The construction and features of a rugged keyboard from Rugged Limited are perfectly matched to the operational requirements of industrial PCs, providing a reliable and long-lasting input solution.

    Rugged Limited offers a variety of rugged keyboards, and many of these models come equipped with backlit keys. This feature is particularly beneficial for professionals operating in environments with challenging lighting conditions, such as during night shifts or in dimly lit industrial settings. The backlighting ensures that each key is clearly visible, thereby reducing errors and improving operational efficiency.

    Our selection of rugged keyboards includes options where the backlighting is a standard feature, designed to meet the demands of rigorous use. This ensures that regardless of the ambient light, the keyboard remains fully functional and easy to use, supporting continuous productivity.

    Rugged keyboards are specifically engineered to withstand harsh industrial, public, and mobile conditions. Their robust construction makes them ideal for environments where regular computer input devices would not be durable enough.

    These keyboards commonly feature designs that are fully sealed to protect against dust, dirt, and liquid ingress, often meeting IP (Ingress Protection) ratings. They are also built to resist vibrations, shocks, and extreme temperatures, ensuring reliable performance in challenging settings.

    Common applications for a rugged keyboard include factories, warehouses, marine vessels, and vehicles, as well as public access terminals and kiosks where durability and hygiene are critical. Many models are also designed for easy cleaning and disinfection, making them suitable for medical and food processing industries. For a comprehensive selection of these durable input solutions, explore the range of rugged keyboards available from Rugged Limited.

    Rugged keyboards are engineered to perform reliably in a variety of challenging outdoor environments. They are built with robust materials and often feature sealed designs to protect against ingress from dust, dirt, and water, which are common concerns in outdoor applications. Many models of rugged keyboards are also designed to withstand extreme temperatures, vibrations, and shocks, making them ideal for field operations, industrial settings, and other outdoor work where standard keyboards would quickly fail.

    For those requiring a dependable input solution in harsh conditions, a rugged keyboard provides the necessary resilience. Rugged Limited offers a range of these durable keyboards that ensure continuous functionality, even when exposed to the unpredictable elements of an outdoor environment.

    Rugged Limited specialises in providing industrial-grade input solutions, including rugged keyboards, designed to operate reliably in challenging conditions. These keyboards are built to withstand elements such as extreme temperatures, dust, dirt, liquids, and heavy usage, which are common causes of failure for standard peripherals.

    By preventing premature failure and reducing the need for frequent replacements or repairs, a rugged keyboard inherently contributes to less operational downtime. Their robust construction ensures consistent performance, enabling uninterrupted work in industries where reliability is paramount. Rugged Limited’s keyboards are engineered for longevity and resilience, giving businesses peace of mind and supporting continuous operations.

    Explore Rugged Limited’s range of rugged keyboards to find a solution that meets your specific industrial needs and helps minimise downtime.

    Rugged keyboards are an excellent choice for control rooms, where reliability and durability are paramount. These environments often require equipment that can endure continuous use and potential exposure to dust or spills without compromising performance.

    Specifically designed with robust materials, a rugged keyboard offers superior protection compared to standard keyboards. This resilience ensures that critical operations in control rooms can proceed uninterrupted, even in challenging conditions. Rugged Limited provides a range of these specialized input devices, built to meet the rigorous demands of such settings, ensuring long-lasting functionality and consistent performance.

    Rugged Limited’s range of industrial keyboards are rigorously tested and certified to meet the demands of challenging environments. Our rugged keyboards are designed to withstand conditions that would compromise standard peripherals.

    Key certifications and ratings for our keyboards include:

    • IP Ratings: Our keyboards often feature high Ingress Protection (IP) ratings, such as IP65, IP67, and IP68. These ratings indicate resistance to dust, dirt, and liquids, making them suitable for washdown areas and environments prone to spills.
    • IK Ratings: Many models also possess IK ratings, signifying their resistance to external mechanical impacts. An IK rating ensures the keyboard can endure significant physical stress without functional impairment.
    • ATEX Certification: For hazardous environments where explosive atmospheres may be present, selected rugged keyboard models are ATEX certified. This certification confirms compliance with essential health and safety requirements relating to explosive atmospheres, ensuring safe operation in such critical zones.

    These certifications collectively ensure that a Rugged Limited rugged keyboard delivers reliable performance and longevity, even in the most demanding industrial, marine, and outdoor settings.
