RUGGED RKB-D343TP-FN Industrial Rugged Keyboard

The RUGGED RKB-D343TP-FN Industrial Rugged Keyboard is built around an IP65-rated dust-sealed membrane design and an industrial metal dome PCB with gold-on-gold key switches, supporting precise and reliable data entry in harsh environments. Its ruggedised touchpad provides accurate cursor control while the 3.0mm thick oxidised aluminium plate and stainless steel frontplate add structural durability for industrial and public sector deployments. The keyboard operates effectively from -20 C to +60 C and resists humidity up to 90%, suitable for continuous-duty use across manufacturing and logistics contexts. Scratch-resistant and featuring anti-microbial surfaces, it is optimised for hygiene and frequent cleaning. Compliance with IEC 61000 and EN 55022/24 standards ensures electromagnetic compatibility in busy industrial settings.

The top-panel mount design offers straightforward installation in operator consoles or machinery control stations. With over 50,000 hours of lifespan and a low mean time to repair under 30 minutes, the RKB-D343TP-FN delivers reliability-engineered ruggedness for demanding data input tasks.

RKB-D343TP-FN Features

  • Rugged Panel Mount Keyboard
  • Integrated Touchpad
  • IP65 Rated
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

Manufacturer

Certifications & Standards

Ruggedness

IP Rating

Mounting Format

Country Of Manufacture

China

Case Material

Membrane Black

Certifications

RoHS , CE, FCC, ESD

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

343.0mm x 125.0mm

Housing Colour

Stainless Steel

Humidity

90% Humidity Resistant

Ball Material

stainless steel

Compatibility

All Windows, Linux, Unix, Mac OSX, Vxworks, Android

EMC

IEC 61000-4-2:2008; IEC 61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004

EMI

EN 55022: 2010

EMS

EN 55024:2010

Frontplate Material

1.5mm Thickness Super Quality Brushed Stainless Steel

Key Material

Membrane

Key Spacing

11.0mm x 11.0mm

Key Switch

Gold-on-Gold key Switch Technology

Lifespan

> 3 years

Material (Bottom Plate)

3.0mm Thickness Brushed & Oxidized Aluminium

MTBF

>50000H

MTTR

<30min

No. Of Keys

81

Operating Force

1.0N

Pointing Device

Touchpad

Power

+5V DC +/-5% appr. 120mA

Product Weight

0.8KGs

Resolution

+400 DPI

Supply Current

appr. 20mA

Supply Voltage

+5V DC +/-5%

Switch / Key Travel

0.45mm

Trackball Diameter

38.0mm

Length

125.0mm

Operating Temperature

Operating temperature:-20C to +60C

Storage Temperature

Storage temperature: -30C to +70C

Temperature Rating

Rating: -20C to +50C

Width

343.0mm

The RUGGED RKB-D343TP-FN Industrial Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The RKB-D343TP-FN supports a wide range of industries and operational applications.

Common deployment industries include: Food And Beverage Processing, Healthcare And Medical, Industrial Manufacturing, Logistics And Supply Chain, Pharmaceutical, Public Sector, Retail, Warehousing.

Across these sectors, the RKB-D343TP-FN is typically used in applications such as ATEX And Hazardous-Area Data Capture, Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, Quality Control And Inspection, SCADA And Control-Room Access, Secure Access, Authentication, And Control Terminals.

These examples demonstrate the versatility of the RKB-D343TP-FN across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the RKB-D343TP-FN is appropriate for your specific application, please contact us.

The RUGGED RKB-D343TP-FN Industrial Rugged Keyboard comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, RUGGED RKB-D343TP-FN Industrial Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the RUGGED RKB-D343TP-FN Industrial Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the RUGGED RKB-D343TP-FN Industrial Rugged Keyboard, or would you like to discuss a customised solution?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the RUGGED RKB-D343TP-FN or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.

  • Alternative Products

    Explore alternative products offering comparable features, performance, and build quality to the model you are currently viewing.

    Our related solutions provide variations in configuration, functionality, and form factor to suit different application requirements. Each option has been selected to meet the same high standards of reliability and performance.

    Browse the related products below to identify the most suitable fit for your deployment.

    • IP65 dust and water sealed
    • Over 10 million key actuations lifespan
    • Vibration tested 20Hz to 2kHz
    • Compatible with multiple OS including Windows Linux iOS
    • Stainless steel housing for durability
    • IP65 sealed against dust and water ingress
    • Over 50,000 hours key switch lifespan
    • 50mm mechanical trackball for precision
    • IP65 sealed chassis
    • Integrated touchpad with USB or PS2 interface
    • Over 10 million keystroke lifespan
    • Wide operating temperature range -40°C to +70°C
    • IP68 sealed silicone rubber construction
    • Antimicrobial surface for hygiene
    • MIL-STD shock and vibration tested
    • Carbon-on-gold tactile key switches
  • Having trouble finding what you're looking for?

    Selecting the correct solution for your specific application and operating environment requires careful consideration.

    At Rugged, our engineering and product specialists can advise on specifications, environmental suitability, mounting requirements, connectivity, and lifecycle planning to ensure the right fit for your deployment.

    With extensive industry experience and a focus on reliability and performance, we help you select a solution aligned with your operational requirements.

    Speak to a Product Specialist
  • Frequently Asked Questions

    Yes, many of the rugged keyboards available from Rugged Limited are engineered to be compatible with both Windows and Linux operating systems. This broad compatibility ensures that users can integrate a durable and reliable rugged keyboard into diverse computing environments without issues.

    Rugged Limited provides a selection of rugged keyboards that are built to withstand challenging conditions while maintaining essential functionality across different platforms. When selecting a rugged keyboard, it is always advisable to check the specific product’s technical specifications to confirm compatibility with your intended operating system.

    Rugged Limited’s range of industrial keyboards are rigorously tested and certified to meet the demands of challenging environments. Our rugged keyboards are designed to withstand conditions that would compromise standard peripherals.

    Key certifications and ratings for our keyboards include:

    • IP Ratings: Our keyboards often feature high Ingress Protection (IP) ratings, such as IP65, IP67, and IP68. These ratings indicate resistance to dust, dirt, and liquids, making them suitable for washdown areas and environments prone to spills.
    • IK Ratings: Many models also possess IK ratings, signifying their resistance to external mechanical impacts. An IK rating ensures the keyboard can endure significant physical stress without functional impairment.
    • ATEX Certification: For hazardous environments where explosive atmospheres may be present, selected rugged keyboard models are ATEX certified. This certification confirms compliance with essential health and safety requirements relating to explosive atmospheres, ensuring safe operation in such critical zones.

    These certifications collectively ensure that a Rugged Limited rugged keyboard delivers reliable performance and longevity, even in the most demanding industrial, marine, and outdoor settings.

    Rugged Limited specialises in providing industrial solutions, and this includes offering customisation options for their rugged keyboard range. We understand that different industries and applications have unique demands, which is why our rugged keyboards can be tailored to incorporate various features.

    For instance, standard options like integrated pointing devices, backlighting, and different mounting solutions are available to enhance functionality and usability. Beyond these, Rugged Limited can implement bespoke modifications to ensure the rugged keyboard seamlessly integrates into your specific setup and operational environment. This commitment to customisation ensures that you receive a product perfectly suited to your needs, rather than a one-size-fits-all solution.

    Rugged Limited offers a range of rugged keyboards that are specifically engineered for panel mounting. These keyboards are designed for seamless integration into various industrial and commercial control panels, kiosks, and other equipment where a durable and reliable input solution is essential.

    Our panel mount rugged keyboards are built to withstand challenging environments, often featuring robust stainless steel construction, sealed keypads for protection against dust and liquids, and vandal-resistant designs. This ensures consistent performance and longevity, even in demanding operational settings.

    When selecting a rugged keyboard for panel mounting, it’s important to consider factors such as the required IP rating, key layout, and connectivity options to ensure it meets the specific needs of your application.

    Rugged Limited understands the importance of durability in demanding environments, which is why our rugged keyboards are often built with chemical resistance in mind. This feature is crucial for industries where keyboards are regularly exposed to harsh cleaning agents, disinfectants, or other industrial fluids.

    Our rugged keyboards are frequently constructed from materials and with designs that prevent the ingress of liquids and corrosive substances, ensuring continued functionality and longevity. This chemical resistance contributes to the overall robustness and reliability of the keyboard, making it suitable for sectors such as healthcare, manufacturing, and food processing, where hygiene and exposure to various chemicals are common.

    The ability of a rugged keyboard to withstand such exposure means less downtime for cleaning and maintenance, and a longer operational lifespan, providing excellent value for our customers.

    Rugged Limited’s rugged keyboards are engineered with long lifecycle availability as a core consideration, making them a reliable choice for industrial and challenging settings. This focus on longevity means that the keyboards are built to withstand continuous use and harsh conditions, reducing the need for frequent replacements.

    The design principles behind these rugged keyboards prioritise durability and sustained performance. By utilising robust materials and manufacturing processes, Rugged Limited ensures that their keyboards offer extended operational lifespans, providing consistent functionality over many years of service. This commitment to long-term availability is a significant advantage for businesses seeking dependable input solutions.

    Rugged Limited offers a range of durable keyboards, and while the exact level of environmental protection can vary by model, many of our rugged keyboards are engineered to withstand exposure to liquids.

    These robust input devices are often designed with features to prevent water ingress, making them suitable for industries where spills, splashes, or wash-downs are common. For specific details on the waterproof ratings of a particular rugged keyboard, it’s always best to consult the individual product specifications.

    An Ingress Protection (IP) rating is a critical standard for rugged keyboards, specifying the degree of protection provided against dust, dirt, and water. This two-digit code is internationally recognised and helps users understand how well a device can withstand environmental factors.

    The first digit in an IP rating signifies protection against solid objects, ranging from 0 (no protection) to 6 (dust-tight). A higher number here means greater resistance to particles entering the device.

    The second digit indicates protection against liquids, ranging from 0 (no protection) to 9 (withstanding high-pressure, high-temperature jet sprays). This is particularly important for a rugged keyboard that might be exposed to spills, rain, or even submersion. Rugged Limited offers a range of peripherals engineered to meet these demanding standards.
