Robustel R1520 Dual-SIM Cellular VPN Router
Designed for industrial and transport environments, the Robustel R1520 Dual-SIM Cellular VPN Router delivers secure and reliable cellular connectivity in harsh conditions. Its rugged plastic housing is impact-resistant and dust-protected, suited for outdoor and vehicle-based deployments. Dual SIM slots ensure continuous network availability with broad frequency band support across global regions including EMEA, China, Japan, and Oceania. The device offers multiple Ethernet ports and serial interfaces (RS-232, RS-485) for flexible integration with sensors and legacy systems, enhancing connectivity in complex setups.
The router meets IEC 61000 electromagnetic immunity and surge resistance standards, supporting operational stability amid electrical interference. Built-in VPN options such as IPsec and OpenVPN safeguard data transmissions, while watchdog and timer features promote durable, low-maintenance use. Certified with an E-mark for automotive compliance, the R1520 fits challenging network scenarios requiring sealed, field-ready hardware for continuous-duty deployment.
R1520 Features
- Cost-effective & high performance 3G/4G router
- Rugged design with 9 to 36Vdc power
- Global4G version available
- E-mark certification for in vehicle use
- Optically isolated digital IO
- 10-bit Analogue interface for direct sensor connections
- Supports Dual SIMs & Wifi/Ethernet as WAN
- Cellular keep-alive and fast failover
- Extensive range of software “apps” for enhanced functionality
Request a Quote
Product Type
Manufacturer
Certifications & Standards
Ruggedness
IP Rating
Mounting Format
Country Of Manufacture
China
Antenna Connectors
2
Available Apps
L2TP, PPTP, DMVPN , VRRP, QoS, Captive Portal, WLAN Multi AP, SNMP, Language, RCMS
Built-in
External RTC clock , Backup energy storage capacitor can be maintained for 2 days, Watchdog, Timer
Case Material
Rugged Plastic
Cellular Connectors
SMA-K
Cellular Region
EMEA,China,Japan,Oceania
Console Connectors
1 x 480Mbps high-speed USB2.0 interface, 1 x GPS interface (Optional, depending on the cellular module)
Custom Options Products
Custom Logo,Case Colour,Connections,Conformal Coating,Anti-Bacterial Coating,Laser Etching,Power Supply,Mounting Options
DI/DO Absolute MAX ADC
10mA(DI/DO)
DI/DO Absolute MAX VDC
30V DC(DI/DO)
DI/DO Connector
2 * 3-pin 3.5 mm female socket
DI/DO Isolation
3 KV
DI/DO Signal Definition
3 to 30V DC = HIGH, 0 to 1 Vdc = LOW
DI/DO Type
1 x DI + 1 x DO, wet contact
Emissions / Immunity
EN 55032: 2012/AC: 2013 (CE & RE) Class B, IEC 61000-4-2 (ESD) Contact Level 2 IEC 61000-4-3 (RS) Level 2 IEC 61000-4-4 (EFT) Level 2 IEC 61000-4-5 (Surge) Level 2 IEC 61000-4-6 (CS) Level 2 IEC 61000-4-11 (DIP) Level 2
Ethernet Ports
5 x 10/100 Mbps, 5 LAN by default, can be configured as 1 WAN + 4 LAN - WAN Support 802.3af & 802.3at PD feature on ETH0
Firewall
DMZ, anti-DoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control
Frequency Bands
China 4G: LTE FDD:B1/B3/B5/B8; LTE TDD: B38/B39/B40/B41 3G: WCDMA: B1/B8; TD SCDMA: B34/B39; CDMA: BC0 2G: GSM: 900/1800 MHz Oceania 4G: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28; LTE TDD: B40 3G: WCDMA: B1/B2/B5/B8 2G: GSM: B2/B3/B5/B8 Japan 4G: LTE FDD: B1/B3/B8/B18/B19/B26; LTE TDD: B41 3G: WCDMA: B1/B6/B8/B19 EMEA, North America,China, 4G: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/ B18/ B19/B20/B25/B26/B28 LTE TDD: B38/B39/B40/B41 3G: WCDMA: B1/B2/B4/B5/B6/B8/B19 2G: GSM: 850/900/1800/1900 MHz EMEA 4G: LTE FDD: B1/B3/B7/B8/B20/B28A 3G: WCDMA: B1/B8 2G: GSM: B3/B8
Housing Colour
Black
Magnet Isolation Protection
1.5 KV
Ordering Info
R1520 Dual-SIM Cellular VPN Router
Power Consumption
Idle: 100 mA@12 V Data link:1.0 A (peak) @12 V
Power Input
9 to 36V DC
Power Supply Connector
2 pin 3.5 mm socket with lock
Remote Management
Web, CLI, SMS
Reset Button
1 x RST
SDK Flash
4 MB
SDK Language
C, C++
SDK RAM
64 MB
Serial Baud Rate
RXD TXD SGND RTS CTS(RS-232) Data+ (A),Data- (B),ground(GND);(RS-485)
Serial Ports
1 x RS-232 + 1 x RS-485 serial port - 2 * 4-pin 3.5 mm female socket
SIM Slots
2 Mini SIM (2 FF)
Network Protocols
PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, Telnet, VLAN, SSH2, DDNS, etc.
Status LED
1 x RUN, 1 x MDM, 1 x USR, 1 x RSSI, 1 x WiFi
VPN Tunnel
IPsec, OpenVPN, GRE
WI-FI Antennas
2
WI-FI Connectors
RP-SMA-K
WI-FI Data Speed
2*2 MIMO, 300 Mbps
WI-FI Encryption
64/128 AES, TKIP
WI-FI Frequency Bands
2.4 GHz
WI-FI Security
WEP, WPA, WPA2
WI-FI Standards
802.11b/g/n, supports AP and Client modes
The Robustel R1520 Dual-SIM Cellular VPN Router is designed and engineered for use in demanding environments where reliability, durability are essential. The R1520 supports a wide range of industries and operational applications.
Common deployment industries include: Construction, Energy and Utilities, Industrial Manufacturing, Logistics And Supply Chain, Marine And Offshore, Oil and Gas, Public Sector, Rail And Transport.
Across these sectors, the R1520 is typically used in applications such as Asset Tracking And Management, Fleet Management And Telematics, Industrial HMI And Machine Interfacing, Process Control And Shop-Floor Monitoring, Route Planning And Navigation, SCADA And Control-Room Access, Secure Communications And Command-And-Control, Vehicle-Mounted Computing (MDTs / VMCs).
These examples demonstrate the versatility of the R1520 across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the R1520 is appropriate for your specific application, please contact us.
The Robustel R1520 Dual-SIM Cellular VPN Router comes with a 2 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Robustel R1520 Dual-SIM Cellular VPN Router, must be presented to RUGGED in the United Kingdom.
For more information about the Robustel R1520 Dual-SIM Cellular VPN Router or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Robustel R1520 Dual-SIM Cellular VPN Router, or would you like to discuss a customised solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Robustel R1520 or need a custom Cellular Router solution designed specifically for you, our team of technical experts are ready to assist you.
