iKey SL-86-911-FSR-OEM Rugged Keyboard

This product has reached End of Life (EOL) status and is no longer in production. Manufacturer support, updates, and spare parts may be discontinued.

All information is provided for reference only. Availability cannot be guaranteed.

Please contact us to discuss current alternatives or recommended replacement models.

Designed for industrial and field environments, the iKey SL-86-911-FSR-OEM Rugged Keyboard provides a reliable input solution resistant to dust, moisture, and mechanical stress. It features an industrial silicone rubber overlay with tactile mechanical snap keys designed to endure over 10 million keystrokes, ensuring long-term durability under continuous-duty use. Built to withstand vibrations and shocks per MIL-STD standards and sealed to IP and NEMA 4X, it offers protection against dust and liquid ingress while operating between -20 6C and +60 6C. The keyboard also meets UL60950 safety standards and offers full compatibility with Windows and Macintosh operating systems through a single USB cable connection.

The integrated force-sensing resistor delivers precise cursor control without requiring additional peripherals, ideal for compact or mobile setups. Its compact dimensions and robust housing make it suitable for challenging environments in manufacturing, defence, and healthcare applications requiring consistent performance and operational resilience.

SL-86-911-FSR-OEM Features

  • 86-Key Functionality + One-Touch Emergency Key
  • Integrated LED Backlighting
  • Integrated Force Sensing Resistor
  • USB and PS2 Configurations Available
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

Manufacturer

Certifications & Standards

Ruggedness

IP Rating

Mounting Format

Interface

Country Of Manufacture

United States

Backlight

Green

Case Material

No Case

Certifications

IP Rated, NEMA 4X UL60950, FCC Part 15 Class B

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

11.12" x 6.05" x 0.72" (w-h-d) 282.4mm x 153.7mm x 18.3mm

Housing Colour

Black

Humidity

100% Humidity Resistant (when properly installed)

Cable

Single-Cable USB

Compatibility

All Windows and Macintosh Operating Systems

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO

Function Keys

10 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 ACTUATION FORCE: 200g (+/- 20g) FEEDBACK: Tactile with mechanical snap

Lifespan

>10 Million Actuations

No. Of Keys

86

Pointing Device

Force Sensing Resistor

Power

KEYBOARD: 200mA@5V (from Keyboard port) HULAPOINT: 35mA@5V (from Mouse port) USB: 235mA@5V (from CPU port)

Product Weight

0.45 kg

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

200g (+/- 20g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to +60C (-4F to +140F)

The iKey SL-86-911-FSR-OEM Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The SL-86-911-FSR-OEM supports a wide range of industries and operational applications.

Common deployment industries include: Defence And Military, Emergency Services, Energy and Utilities, Healthcare And Medical, Industrial Manufacturing, Logistics And Supply Chain, Public Sector.

Across these sectors, the SL-86-911-FSR-OEM is typically used in applications such as Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Medical Carts And Clinical Mobile Workstations, Process Control And Shop-Floor Monitoring, Secure Access, Authentication, And Control Terminals, Secure Communications And Command-And-Control.

These examples demonstrate the versatility of the SL-86-911-FSR-OEM across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the SL-86-911-FSR-OEM is appropriate for your specific application, please contact us.

The iKey SL-86-911-FSR-OEM Rugged Keyboard comes with a 90 Day Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey SL-86-911-FSR-OEM Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey SL-86-911-FSR-OEM Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey SL-86-911-FSR-OEM Rugged Keyboard, or would you like to discuss a customised solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iKey SL-86-911-FSR-OEM or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
