iKey BT-80-TP Bluetooth Rugged Keyboard

Designed for industrial and field operations, the iKey BT-80-TP Bluetooth Rugged Keyboard delivers a sealed, wireless input solution built to withstand exposure to moisture, dust, and temperature extremes. Its ABS polycarbonate housing meets IP68 and NEMA 4X standards, offering high ingress protection against water and particulates. This compact device features industrial silicone rubber keys with tactile, mechanical snap feedback for reliable data entry even in challenging environments.

A rechargeable lithium-ion battery supports continuous wireless use, while adjustable red LED backlighting aids visibility in low light. The keyboard is shock resistant and vibration tolerant, having been tested to MIL-STD-810G standards, enhancing durability for mobile or industrial applications. Temperature ratings from -20 6C to +60 6C ensure dependable operation across diverse settings. The integrated touchpad further supports efficient control in environments such as manufacturing, emergency services, energy, and medical sectors requiring rugged, continuous-duty input peripherals.

BT-80-TP Features

  • Fully Sealed, Compact IP68 / NEMA 4X
  • Bluetooth Wireless Technology
  • Adjustable LED Backlighting
  • Integrated Touchpad
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

Manufacturer

Certifications & Standards

Ruggedness

IP Rating

Mounting Format

Country Of Manufacture

United States

Backlight

Red

Case Material

ABS Polycarbonate

Certifications

IP68

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

10.04" x 7.41" x .71"

Housing Colour

Black

Humidity

100% Humidity Resistant

Cable

LENGTH: 5.4' straight (1.6 m) DESIGN: Single cable USB

Compatibility

Mac OS and iOS

Connectivity

Wireless , Bluetooth

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 million cycles TRAVEL: 0.055" ACTUATION FORCE: 7.05 oz +/- 1.06 oz (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap

Lifespan

>10 Million Actuations

No. Of Keys

80

Pointing Device

Touchpad

Power

Bluetooth: Rechargeable Lithium Ion Battery

Product Weight

1.2 +/- 0.10 lbs (0.54 +/- 0.05kg)

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

200g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40F to +158F (-40C to +70C) OPERATING: -4F to +140F (-20C to +60C)

The iKey BT-80-TP Bluetooth Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The BT-80-TP supports a wide range of industries and operational applications.

Common deployment industries include: Defence And Military, Emergency Services, Energy and Utilities, Healthcare And Medical, Industrial Manufacturing.

Across these sectors, the BT-80-TP is typically used in applications such as Emergency Dispatch And Incident Management, Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Medical Carts And Clinical Mobile Workstations, Mobile Workforce Operations, Process Control And Shop-Floor Monitoring, Secure Communications And Command-And-Control, Vehicle-Mounted Computing (MDTs / VMCs).

These examples demonstrate the versatility of the BT-80-TP across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the BT-80-TP is appropriate for your specific application, please contact us.

The iKey BT-80-TP Bluetooth Rugged Keyboard comes with a Standard Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey BT-80-TP Bluetooth Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey BT-80-TP Bluetooth Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey BT-80-TP Bluetooth Rugged Keyboard, or would you like to discuss a customised solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iKey BT-80-TP or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
