Digi IX10-00G4 Cellular Router

Digi IX10 is a full-featured cellular router built for trouble-free reliability over a long service life. Its flexible power and connectivity options make it a versatile and cost-effective choice for industrial, digital signage, ATMs, lottery terminals, kiosks and other unattended retail applications that need to provide secure transactions.

Digi IX10 features an RJ-45 serial port supporting both RS-232 and RS-485, as well as dual SIMs for redundant connection. It can operate independently on LTE networks, with features to assist in network control and management, such as VLAN support, load balancing between cellular and Ethernet WANs, dual APNs and configurable APN search.

Digi IX10 also offers low-touch and no-touch provisioning. ain critical insights into your deployed devices and manage your network with Digi Remote Manager ® (Digi RM) the command centre for your deployment. Digi RM is a cloud-based solution that facilitates easy setup, mass configuration, maintenance and support, even for thousands of devices. Digi RM empowers you to evaluate, update and configure your Digi enterprise products while providing easy visibility into the health of your network. In the event of an interruption to your primary network connection, Digi RM also provides secure terminal access for out-of-band management access to edge devices via Digi IX10 via serial port and command-line interface. In addition, Digi IX10 offers the convenience of a global SKU which simplifies inventory control for global distribution and deployment.

IX10-00G4 Features

  • Compact and economical cellular routing platform
  • Redundant connectivity with dual SIMs and Digi SureLink
  • Built-in Digi TrustFence for device security, device identity and data privacy
  • Ethernet port and single RJ-45 serial port (RS-232/485)
  • Digi Remote Manager platform for easy setup, mass configuration and out-of-band management
  • Global bands and single part number to simplify global distribution, deployment and management

Request for Quote (RFQ)

Product Type

Manufacturer

Country Of Manufacture

United States

Approvals / Certifications

IEC62368-1, CB, EN62311, ROHS3

Box Content

Digi IX10-00G4 - LTE Cat 4 Global, (1) Ethernet, RS-232/485

Case Material

Metal

Cellular Connectors

(2) 50 SMA (center pin: female)

Custom Options Products

Case Colour,Conformal Coating,Laser Etching,Power Supply,Mounting Options

Dimensions

(L X W X H) 118 mm x 88 mm x 35 mm (4.65 in x 3.46 in x 1.38 in)

Emissions / Immunity

CE; RED; FCC Part 15, Subpart B; ICES-003; AU/NZS CISPR32

Ethernet

(1) RJ-45; 10/100 Mbps (auto-sensing)

Housing Colour

Black

Humidity

5% to 95% (non-condensing)

Local Management

WebUI (HTTP/HTTPS); CLI (Telnet, SSH)

LTE (G4)

LTE Cat 4: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B38, B39, B40, B41; 3G: B1, B2, B4, B5, B6, B8, B19; 2G EDGE / GPRS: 850 / 900 / 1800 / 1900 MHz

Management/Troubleshooting Tools

FTP client, SCP; protocol analyzer with PCAP for Wireshark; event logging with syslog and SMTP client; NTP/SNTP; Nagios, Intelliflow, iPerf, Dynamic DNS, ping, traceroute

Memory

256 MB RAM, 256 MB flash

Power Supply

9 - 30 VDC, 1.0 A maximum - 2.5 W typical (idle); 6 W typical (peak Tx/Rx)

Serial I/O

(1) RJ-45 10-pin (10P10C); RS-232/485; software selectable- RS-232 DTE (RXD, TXD, RTS, CTS, DTR, DCD, DSR, RI)- RS-485 (TX/RX+; RX/TX-); half-duplex

Operating Temperature

Minus 40 degrees celsius to 70 degrees celsius; device performance may be impacted above 50C (122 F)

Ordering Info

Digi IX10-00G4 - LTE Cat 4 Global, (1) Ethernet, RS-232/485

Remote Management

Digi Remote Manager; SNMP v2/v3 (user installed/managed)

SIM Security

Behind SIM cover, secured with screw (#1 Phillips)

SIM Slots

(2) Mini-SIM (2FF)

Status LED

Power, Internet, SIM 1, SIM 2, SIM fail, LTE, signal strength (5)

Storage Temperature

Minus 40 degrees celsius to 85 degrees celsius

The Digi IX10-00G4 Cellular Router is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the IX10-00G4 is commonly used:

Aerospace, Industrial and Manufacturing, Marine and Offshore, Medical and Healthcare, Military and Defence, Outdoor and Mobile Computing, Pharmaceutical, Public Safety and Emergency Services, Transport and Logistics

These examples highlight the versatility of the Digi IX10-00G4 Cellular Router across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Cellular Router fits your specific needs, please contact us.

The Digi IX10-00G4 Cellular Router comes with a 3 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, Digi IX10-00G4 Cellular Router, must be presented to RUGGED in the United Kingdom.

For more information about the Digi IX10-00G4 Cellular Router or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
