iBASE IP380L CPU Card
Designed for industrial computing environments, the iBASE IP380L CPU Card delivers robust processing within PICMG 1.3 backplane systems. Its industrial-grade design supports operation from -20 to 80°C and endures up to 90% non-condensing humidity, making it suitable for field-ready deployments. The card integrates an Intel C236 chipset with AMI BIOS and supports 6th Generation Intel Xeon and Core processors, enabling reliable, continuous-duty performance. It accommodates up to 32GB ECC DDR4 memory for error-resilient processing, essential for long operational cycles.
Connectivity options include dual Gigabit LAN PHY controllers (Intel I219LM and I211AT), multiple serial ports with jumperless selection, and six SATA III interfaces, providing extensive I/O flexibility. Supporting DVI-I, VGA, and DVI-D display interfaces, the IP380L meets MIL-STD shock and vibration criteria and is RoHS and CE certified, confirming suitability for harsh industrial use. These credentials affirm the IP380L as a reinforced CPU card for secure and stable industrial-grade platforms.
IP380L Features
- 4-Layer PCB
- At / ATX Power Connector
- 1X PCI-E 16-Lane Slot, 3X PCI-E 1-Lane Slot
- Picmg 1.3 Connector (A: PCI-E X16, B: PCI-E X8, C: PCI-E X16, D: PCI-E X8), 4X PCI (32-Bit) Slot
- Size: 221mm X 328mm (8.7" X 12.9)
- Watchdog Timer, Digital I/O, Iamt(11.0)
Request a Quote
Certifications
RoHS Compliant, CE
Dimensions
338mm x 126mm (13.31" x 4.96")
Audio
Intel C236 PCH built-in HD audio controller + Realtek ALC662 w/ 5.1 channel
BIOS
AMI BIOS
Display Interface
Support DVI-I, VGA, DVI-D
Expansion Slots
1x Mini PCI-E
Form Factor FILTER
Backplane
H/W Monitor
Yes
I/O Chipset
Fintek F81846AD-I 1x RS-232/422/485(Jumperless selection) 3x RS232, 6x SATA III, 1x LPT
LAN Connector
2x RJ-45 on board
LAN Controller
Intel I219LM Gigabit LAN PHY Intel I211AT PCI-E Gigabit LAN( as 2nd LAN)
Others
Digital I/O (4-in/4-out), RAID, iAMT (11.0)
SSD
N/A
System Memory
2 x DDR4-2133 DIMM, Max 32GB (ECC compatible)
USB
3 ports x USB3.0 on board 2 ports x USB2.0 via pin header 1 port x USB2.0 via Mini PCI-E
VGA Controller
6th Generation Intel Core DT Xeon E3 & Core i7/i5/i3/Pentiumï¾®/ Celeron integrated graphics
VGA Memory
Max. shared memory 1024MB
Watchdog Timer
256 levels
Expansion
Mini PCI-E
Form Factor
CPU Card
Humidity
90% Humidity Resistant (non-condensing @ 60C)
Operating Temperature
0C ~ 60C (32CF ~ 140CF)
Ordering Info
IP380L / IP380-R PICMG 1.3 8-slot Backplane with 1x PCI-E 16-lane slot and 3x PCI-E 1-lane slot , 4x PCI
Processor
Intel
Storage Temperature
-20C ~ 80C (-4CF ~ 140CF)
The iBASE IP380L CPU Card is designed and engineered for use in demanding environments where reliability, durability are essential. The IP380L supports a wide range of industries and operational applications.
Common deployment industries include: Defence And Military, Energy and Utilities, Industrial Manufacturing, Logistics And Supply Chain, Marine And Offshore, Natural Resources and Mining, Oil and Gas, Rail And Transport.
Across these sectors, the IP380L is typically used in applications such as Industrial HMI And Machine Interfacing, Predictive Maintenance And Condition Monitoring, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, SCADA And Control-Room Access.
These examples demonstrate the versatility of the IP380L across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the IP380L is appropriate for your specific application, please contact us.
The iBASE IP380L CPU Card comes with a Standard Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE IP380L CPU Card, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE IP380L CPU Card or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
