Winmate R17IAD7T-RKM1 17 Inch Rack Mount Panel PC
Designed for industrial and data centre environments, the Winmate R17IAD7T-RKM1 17 Inch Rack Mount Panel PC provides reliable performance in compact 9U rack spaces. Its robust metal housing and sealed enclosure protect against dust and particulate ingress, while the fan cooling system supports continuous-duty operation within a 0°C to 50°C range. The 17-inch display with 1280×1024 resolution delivers clear visibility for monitoring and control tasks in high-density server racks.
The system supports Intel’s Alder Lake S series processors, including options up to Core i9, ensuring dependable processing power. Dual 2.5 Giga LAN ports enhance network throughput, and TPM 2.0 security safeguards critical data. USB 3.2 ports and multiple video outputs including DisplayPort and optional HDMI provide versatile connectivity. Certified to CE and FCC standards, this panel PC is built for industrial-grade deployment wherever reliable rack-mounted computing is necessary.
R17IAD7T-RKM1 Features
- 17” 1280 x 1024 Resolution Rack Mount Panel PC
- 12th Gen Intel® Core™ Alder Lake S i9 / i7/ i5 / i3 processor
- 2 x SODIMM, DDR5 4800MHz, support up to 64GB (Max. 32GB for each slot)
- Integrated Dual 2.5 Gigabit Ethernet
- Multi display supports DP 1.4a / HDMI 2.0b (Optional)
- Multiple I/Os, 4 x USB 3.2 Gen2x1, 2 x Serial Ports
- 12 V DC Power input
Request a Quote
Product Type
Manufacturer
Ruggedness
Mounting Format
Screen Size
Country Of Manufacture
Taiwan
Size
17.0 inches
Touch / Glass
Resistive Touch Screen (Optional) Protection Glass Without Touch Function (Optional)
Resolution
1280x1024
Panel Brightness
350.0 nits
Contrast Ratio
1000:1
View Angles
85-85-80-80
Active Area
337.920x270.336 mm
Processor
Intel® Core™ i5-12500TE(up to 4.3GHz) Intel® Core™ i9-12900TE(up to 4.80GHz) (Optional) Intel® Core™ i7-12700TE(up to 4.6GHz) (Optional) Intel® Core™ i3-12100TE(up to 4.00GHz) (Optional)
Chipset
Intel® R680E
Memory
2 x SO-DIMM- DDR5 4800 MHz- 8GB 16GB (Optional) 32GB (Optional) 64GB (Optional)
Storage
1 x M.2 2280 M-Key NVMe SSD 256GB 512GB (Optional) 1TB (Optional) 2TB (Optional) 2 x SATA III for 2.5" SSD/HDD (Only R680E/Q670E version support)(RAID support) (Optional)
Ethernet controller
2 x Intel® Ethernet Controller
Security
TPM 2.0
Operating System
Windows 11 IoT Enterprise (64 bit) (Optional) Windows 11 Pro 64 bit (Optional) Linux Ubuntu 22.04(Do not support Wake on Touch) (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
Dimension
482.6 x 399 x 92 mm
Weight
5.9 kg
Mounting
VESA mount Rack mount (9U) (Optional)
Enclosure
Metal Housing
Cooling System
Fan Design
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
Certification
CE- FCC
USB Port
4 x USB 3.2 Gen2x1 (10Gbps- TypeA) (R680E/Q670E version) 4 x USB 3.2 Gen1x1 (5Gbps- TypeA) (H610E version)
Serial Port
1 x RS232/422/485 (Default RS232) 1 x RS232
LAN
2 x 2.5 Giga LAN RJ45 Connector
Video
1 x DP1.4a DP++ - Max resolution up to 4096x2160@60Hz 1 x HDMI 2.0b - Max resolution up to 4096x2160@60Hz (Optional)
Audio
Mic in Line out
Expansion Port
1 x M.2 2280 M-Key Slot (for NVME SSD) 1 x M.2 2230 E-Key Slot (for Wi-Fi module)
Power Input
1 x 12V DC- Din4 pin connector
Button
1 x Power Button 1 x Reset Button
Accessory
100~240V AC to DC Adapter Power Cord VESA screws
Power Rating
12V DC
Adapter
12V 220W"
The Winmate R17IAD7T-RKM1 17 Inch Rack Mount Panel PC is designed and engineered for use in demanding environments where reliability, durability are essential. The R17IAD7T-RKM1 supports a wide range of industries and operational applications.
Common deployment industries include: Defence And Military, Energy and Utilities, Food And Beverage Processing, Industrial Manufacturing, Logistics And Supply Chain, Pharmaceutical, Public Sector, Rail And Transport.
Across these sectors, the R17IAD7T-RKM1 is typically used in applications such as Emergency Dispatch And Incident Management, Industrial HMI And Machine Interfacing, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, SCADA And Control-Room Access, Secure Communications And Command-And-Control.
These examples demonstrate the versatility of the R17IAD7T-RKM1 across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the R17IAD7T-RKM1 is appropriate for your specific application, please contact us.
The Winmate R17IAD7T-RKM1 17 Inch Rack Mount Panel PC comes with a 1 Year RTB UK Warranty With Option To Extend Upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Winmate R17IAD7T-RKM1 17 Inch Rack Mount Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the Winmate R17IAD7T-RKM1 17 Inch Rack Mount Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Winmate R17IAD7T-RKM1 17 Inch Rack Mount Panel PC, or would you like to discuss a customised solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Winmate R17IAD7T-RKM1 or need a custom Rugged Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
