iKey TMLT-890-TP-OEM Military Grade Rugged Keyboard With Touchpad

For teams working across physically demanding environments, the iKey TMLT-890-TP-OEM military grade rugged keyboard provides reliable data entry under electromagnetic interference and environmental stress. Its sealed design and impact-resistant build suit vehicle mounts and confined spaces where durability is essential. Integrated dual pointing devices combine a Force Sensing Resistor with a capacitive touchpad, offering precise control options. Certified to MIL-461E for EMI resistance and MIL-STD-810F for shock, dust, and moisture resistance, this keyboard supports continuous duty from -32°C to +60°C. An IP-rated NEMA 4X enclosure further confirms protection against industrial contaminants.

Featuring a 94HB silicone rubber key overlay and tactile mechanical snap keys built for over 10 million actuations, it maintains input reliability over extended use. Operating on 5V power with PS2 interface compatibility, it suits industrial Windows OS deployments. With its compact 59 x 42 mm active area and rugged construction, the TMLT-890-TP-OEM balances field readiness with tactile feedback for effective operation even in challenging conditions.

TMLT-890-TP-OEM Features

  • Designed To Meet Mill-Std-461E
  • Integrated Touchpad
  • Integrated Fsr Pointing Device
  • Optional NVIS Compliant Green B Backlighting
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

Manufacturer

Certifications & Standards

Ruggedness

IP Rating

Mounting Format

Country Of Manufacture

United States

Case Material

No Case

Certifications

IP Rated, NEMA 4X UL60950, FCC Part 15 Class B

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

100% (when properly installed)

Humidity

100% Humidity Resistant (when properly installed)

Active Area

59 x 42 mm

Compatibility

All windows OS

Diameter

38 mm

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial silicone rubber LIFE: Greater than 10 million cycles TRAVEL: 0.055 ACTUATION FORCE: 180g (+/- 30g) FEEDBACK: Tactile with mechanical snap

Lifespan

>10 Million Actuations

Mounting Type

front panel with threaded bolts

No. Of Keys

89

Operating Force

1 N

Operating Principle

capacitive

Pointing Device

Touchpad

Pointing Device Operating Principle

Capacitive

Power

300mA@5V KEYBOARD/BACKLIGHT PS2/POINTER PS2/TOUCHPAD

Product Weight

1.4 lbs (0.63 kg)

Resolution

100 - 300 dpi

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

(180g +/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Switching Cycles

approx. 10 mill. (per key)

Tracking Force

65 g

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -51C to +71C OPERATING: -32C to +60C

The iKey TMLT-890-TP-OEM Military Grade Rugged Keyboard With Touchpad is designed and engineered for use in demanding environments where reliability, durability are essential. The TMLT-890-TP-OEM supports a wide range of industries and operational applications.

Common deployment industries include: Aerospace, Defence And Military, Emergency Services, Energy and Utilities, Industrial Manufacturing, Marine And Offshore, Oil and Gas, Rail And Transport.

Across these sectors, the TMLT-890-TP-OEM is typically used in applications such as Aircraft Cockpit And Avionics Support Systems, Emergency Dispatch And Incident Management, Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Mobile Workforce Operations, Quality Control And Inspection, Secure Communications And Command-And-Control, Vehicle-Mounted Computing (MDTs / VMCs).

These examples demonstrate the versatility of the TMLT-890-TP-OEM across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the TMLT-890-TP-OEM is appropriate for your specific application, please contact us.

The iKey TMLT-890-TP-OEM Military Grade Rugged Keyboard With Touchpad comes with a 90 Day Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey TMLT-890-TP-OEM Military Grade Rugged Keyboard With Touchpad, must be presented to RUGGED in the United Kingdom.

For more information about the iKey TMLT-890-TP-OEM Military Grade Rugged Keyboard With Touchpad or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey TMLT-890-TP-OEM Military Grade Rugged Keyboard With Touchpad, or would you like to discuss a customised solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iKey TMLT-890-TP-OEM or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
