R15L600-65C3 Winmate 15 Inch IP65 Stainless Resistive Chassis Display
The Winmate R15L600-65C3 is a rugged 15-inch resistive touch display housed in a stainless steel chassis. With an IP65 rating, this display is protected from dust and water, making it well-suited for harsh industrial environments like food processing plants, pharmaceutical labs, and chemical factories. The resistive touch screen allows for operation even with gloves, enhancing its utility in various industries where hygiene and cleanliness are key. The R15L600-65C3 is built for reliability, with robust materials ensuring long-lasting performance in tough conditions.
R15L600-65C3 Features
- 15”, 1024 x 768
- Support VESA / YOKE mount
- Chassis
- Stainless housing SUS 316 / AISI 316
- Full IP65 waterproof and dustproof
- Optical bonding (optional)
Request for Quote (RFQ)
Size
15.0 inches
Touch / Glass
Resistive Touch Screen (Optional) Protection Glass w/o Touch Function (Optional)
Resolution
1024x768
Panel Brightness
300.0 nits
Contrast Ratio
2000:1
View Angles
88-88-88-88
Display Color
16.2M Colors
Active Area
304.1x228.1 mm
Dimension
378 x 301 x 60 mm
Mounting
VESA Mount Yoke Mount
Enclosure
Stainless Housing
Cooling System
Fanless design
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 45°C
Storage Temperature
-20°C to 60°C
IP rating
IP65
Certification
CE- FCC
USB Port
1x M12 waterproof connector for touch screen control (Optional)
Serial Port
1 x M12 waterproof connector for touch screen control (Optional)
Video
1x M12 type connector for VGA input 1x waterproof DVI input (Optional) 1x waterproof connector for HDMI input (Optional)
Indicator
1 x LED Indicator for power 1 x LED Indicator for status
Power Input
1 x M12 waterproof connector for 12V DC
Button
1 x Power Button 1 x Adjust up button 1 x Adjust down button 1 x ESC (Auto) button 1 x OK (Menu) button
Accessory
100~240V AC to DC Adapter with waterproof connector Power Cord External VGA cable with waterproof connector Waterproof caps Manual VESA screws
Optional Accessory
Yoke mount stand (Optional) External HDMI cable with waterproof connector (Optional) External DVI cable with waterproof connector (Optional) External USB cable with waterproof connector for touchscreen control (Optional) External RS232 cable with waterproof connector for touchscreen control (Optional)
Power Rating
12V DC (M12 type)
The R15L600-65C3 Winmate 15 Inch IP65 Stainless Resistive Chassis Display is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the R15L600-65C3 is commonly used:
These examples highlight the versatility of the R15L600-65C3 Winmate 15 Inch IP65 Stainless Resistive Chassis Display across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Display fits your specific needs, please contact us.
The R15L600-65C3 Winmate 15 Inch IP65 Stainless Resistive Chassis Display comes with a 1 Year RTB UK Warranty With Option To Extend upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, R15L600-65C3 Winmate 15 Inch IP65 Stainless Resistive Chassis Display, must be presented to RUGGED in the United Kingdom.
For more information about the R15L600-65C3 Winmate 15 Inch IP65 Stainless Resistive Chassis Display or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the R15L600-65C3 Winmate 15 Inch IP65 Stainless Resistive Chassis Display or require a custom solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Winmate R15L600-65C3 or need a custom Display solution designed specifically for you, our team of technical experts are ready to assist you.
