TSW200 Teltonika Industrial POE+ Ethernet Switch
TSW200 is an industrial Ethernet switch with 2 SFP ports for long-range Fiber-optic communication and 8 Gigabit Ethernet ports that support IEEE802.af and IEE802.3at Power-over-Ethernet standards. Classified as power source equipment (PSE), it enables the centralization of the power supply, providing up to 30 watts per port and reducing the effort to install power.
TSW200 Features
- 2 x SFP ports for long-range Fiber-optic communication
- 8 x PoE+ ports with 802.af, 802.3at standard support
- Total power budget at PSE up to 240 W
- 8 x Gigabit Ethernet with speeds up to 1000 Mbps
Request for Quote (RFQ)
Product Type
Format
Manufacturer
Country Of Manufacture
Lithuania
ETH
8 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
Fibre
2 x SFP ports
IEEE 802.3 series standards
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
PoE ports
Port 1 - 8
PoE standards
802.3af and 802.3at Alternative B
PoE Max Power per Port (at PSE)
30 W
Total PoE Power Budget (at PSE)
240 W
Bandwidth (Non-blocking)
20 Gbps
Packer buffer
128 KB
MAC address table size
2K entries
Jumbo frame support
9216 bytes
Connector
2-pin industrial DC power socket
Input voltage range
7 – 57 VDC
PoE-out input voltage range
44 – 57 VDC
Power consumption
Idle: 1.81 W / Max: 5.5 W / PoE Max: 245.5 W
Ethernet
8 x RJ45 ports, 10/100/1000 Mbps
Fibre
2 x SFP ports
Status LEDs
1 x Power LED, 16 x ETH status LEDs 2 x SFP status LEDs
Power
1 x 2-pin industrial DC power socket
Other
1 x Grounding screw
Casing material
Full aluminum housing
Dimensions (W x H x D)
132 x 44.2 x 95.1 mm
Weight
517 g
Mounting options
Integrated DIN rail bracket, wall mount, flat surface (additional kit needed)
Operating temperature
-40 °C to 75 °C
Operating humidity
5% to 95% non-condensing
Ingress Protection Rating
IP30
Regulatory
CE, UKCA, CITC, ANRT, FCC, IC, CB
Standards
EN 55032:2015 + A1:2020EN 55035:2017 + A11:2020EN IEC 61000-3-2:2019 + A1:2021EN 61000-3-3:2013 + A1:2019
ESD
EN 61000-4-2:2009
Radiated Immunity
EN IEC 61000-4-3:2020
EFT
EN 61000-4-4:2012
Surge Immunity (AC Mains Power Port)
EN 61000-4-5:2014 + A1:2017
CS
EN 61000-4-6:2014
DIP
EN IEC 61000-4-11:2020
Standards
IEC 62368-1:2018EN IEC 62368-1:2020+A11:2020
The TSW200 Teltonika Industrial POE+ Ethernet Switch is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the TSW200 is commonly used:
Aerospace, Marine and Offshore, Medical and Healthcare, Military and Defence, Outdoor and Mobile Computing, Public Safety and Emergency Services, Transport and Logistics
These examples highlight the versatility of the TSW200 Teltonika Industrial POE+ Ethernet Switch across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Ethernet Switch fits your specific needs, please contact us.
The TSW200 Teltonika Industrial POE+ Ethernet Switch comes with a 24 Month Limited Warrany against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, TSW200 Teltonika Industrial POE+ Ethernet Switch, must be presented to RUGGED in the United Kingdom.
For more information about the TSW200 Teltonika Industrial POE+ Ethernet Switch or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the TSW200 Teltonika Industrial POE+ Ethernet Switch or require a custom solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Teltonika TSW200 or need a custom Ethernet Switch solution designed specifically for you, our team of technical experts are ready to assist you.
