W22L100-STA3 Winmate 21.5 Inch Stainless Panel Mount Display
The Winmate W22L100-STA3 is a 21.5-inch stainless steel panel mount display designed for use in industrial environments where both durability and hygiene are critical. The stainless steel construction provides corrosion resistance, making it suitable for food processing, pharmaceutical, and chemical industries. The panel mount design allows for a secure and seamless installation, while the large screen ensures excellent visibility for monitoring and control tasks. The W22L100-STA3 is built to withstand harsh conditions, offering long-term reliability in demanding applications.
W22L100-STA3 Features
- 21.5", 1920 x 1080, Stainless Panel Mount Display
- VGA and HDMI input
- Panel mount
- VESA mount
Request for Quote (RFQ)
Size
21.5 inches
Touch / Glass
Resistive Touch Screen (Optional) Protection Glass Without Touch Function (Optional)
Resolution
1920x1080
Panel Brightness
250 nits
Contrast Ratio
3000:1
View Angles
89-89-89-89
Display Color
16.7M Colors
Active Area
476.64x268.11 mm
Dimension
544 x 340 x 68 mm
Mounting
Panel mount VESA Mount
Enclosure
Stainless front bezel
Cooling System
Fanless design
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
CE- FCC
USB Port
1x USB type-A for touch screen control (Optional)
Serial Port
1 x RS232 D-sub9 for touch screen control (Optional)
Video
1x VGA input 1x HDMI input (Optional) 1x DVI input (Optional)
Indicator
1 x LED Indicator for power 1 x LED Indicator for status
Power Input
1 x 12V DC- 2.5φ DC jack
Button
1 x Power Button 1 x Adjust up button 1 x Adjust down button 1 x ESC (Auto) button 1 x OK (Menu) button
Accessory
100~240V AC to DC Adapter Power Cord External USB Cable For Touchscreen Control External VGA Cable External HDMI Cable VESA Screws
Optional Accessory
External DVI Cable (Optional)
Power Rating
12V DC
The W22L100-STA3 Winmate 21.5 Inch Stainless Panel Mount Display is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the W22L100-STA3 is commonly used:
These examples highlight the versatility of the W22L100-STA3 Winmate 21.5 Inch Stainless Panel Mount Display across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Display fits your specific needs, please contact us.
The W22L100-STA3 Winmate 21.5 Inch Stainless Panel Mount Display comes with a 1 Year RTB UK Warranty With Option To Extend upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, W22L100-STA3 Winmate 21.5 Inch Stainless Panel Mount Display, must be presented to RUGGED in the United Kingdom.
For more information about the W22L100-STA3 Winmate 21.5 Inch Stainless Panel Mount Display or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
