R15L100-EHC3 Winmate 15 Inch Multi-Touch Panel Mount Monitor
The Winmate R15L100-EHC3 is a 15-inch panel mount monitor designed for industrial applications that require reliable multi-touch capability. Its PCAP technology provides smooth and accurate touch response, even in challenging environments. The panel mount design makes installation straightforward and secure, while the durable construction ensures long-term performance. This display is ideal for use in factory automation, control systems, and industrial monitoring, where both durability and responsiveness are critical.
R15L100-EHC3 Features
- 15", 1024 x 768, touchscreen monitor
- VGA and HDMI input
- Panel Mount
- VESA mount
- PCAP touch
Request for Quote (RFQ)
Size
15.0 inches
Touch / Glass
Projected Capacitive Multi Touch Screen Anti-glare Coating (Optional)
Resolution
1024x768
Panel Brightness
300.0 nits
Contrast Ratio
2000:1
View Angles
88-88-88-88
Display Color
16.2M Colors
Active Area
304.1x228.1 mm
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
CE- FCC
USB Port
1 x USB for Touch Screen
Video
1 x VGA 1 x HDMI (Optional) 1 x DVI (Optional)
Audio
Audio line in (3.5mm) (Optional) 2 x Speaker (Optional)
Dimension
367 x 291 x 65.8 mm
Mounting
VESA Mount/ Panel Mount
Cooling System
Fanless Design
Accessory
1 x VGA cable 1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws(Varies by product)
Optional Accessory
Remote Controller (Optional-Varies by product)
Power Rating
12V DC in 24V DC in (optional)
Button
5 Keys: - - + - Power - Esc - Enter
The R15L100-EHC3 Winmate 15 Inch Multi-Touch Panel Mount Monitor is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the R15L100-EHC3 is commonly used:
These examples highlight the versatility of the R15L100-EHC3 Winmate 15 Inch Multi-Touch Panel Mount Monitor across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Display fits your specific needs, please contact us.
The R15L100-EHC3 Winmate 15 Inch Multi-Touch Panel Mount Monitor comes with a 1 Year RTB UK Warranty With Option To Extend upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, R15L100-EHC3 Winmate 15 Inch Multi-Touch Panel Mount Monitor, must be presented to RUGGED in the United Kingdom.
For more information about the R15L100-EHC3 Winmate 15 Inch Multi-Touch Panel Mount Monitor or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the R15L100-EHC3 Winmate 15 Inch Multi-Touch Panel Mount Monitor or require a custom solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Winmate R15L100-EHC3 or need a custom Display solution designed specifically for you, our team of technical experts are ready to assist you.
