iKey SLK-102-461-FSR Military Grade Backlit Rugged Keyboard

Designed for harsh environments, the iKey SLK-102-461-FSR Military Grade Backlit Rugged Keyboard delivers dependable performance against electromagnetic interference and severe field conditions. Its fully sealed NEMA 4X ABS polycarbonate case protects against dust, water, and sand, making it suitable for industrial and military use. The keyboard features an industrial silicone rubber tactile key overlay rated for over 10 million actuations, ensuring durability with each keystroke. The integrated force sensing resistor technology enables accurate data entry under continuous-duty operation.

Red LED backlit keys support usability in low-light settings, while compliance with MIL-STD-461 and UL60950 assures electromagnetic and electrical safety standards are met. Tested to withstand 50g shock pulses and vibration across three axes, it operates reliably from -40 C to +70 C, confirming its suitability for demanding deployment environments.

SLK-102-461-FSR Features

  • Designed To Meet MIL-STD-461F
  • 12 Function Keys
  • Full-Size Military Keyboard
  • Integrated Pointing Device
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

IP Rating

Manufacturer

Country Of Manufacture

United States

Backlight

Red

Case Material

ABS Polycarbonate

Certifications

NEMA 4X UL60950, FCC Part 15 Class B

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

5.55" x 14.60" x 1.05" (w-h-d) 141mm x 370.9mm x 26.7mm

Housing Colour

Black

Humidity

100% Humidity Resistant

Cable

Single-Cable USB

Compatibility

All Windows and Macintosh Operating Systems

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial Silicone Rubber LIFE: Greater Than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.05 oz. +/- 1.06oz (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap

Lifespan

>10 Million Actuations

No. Of Keys

102

Pointing Device

Force Sensing Resistor

Power

PS/2: KEYBOARD: 210mA@5V (from Keyboard port) HULAPOINT: 35mA@5V (from Mouse port) USB: 245mA@5V (from CPU port)

Product Weight

1.5 lbs +/- 0.10 lbs (0.68 kg +/- 0.05 kg)

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

200g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40F to 194F (-40C to +90C) OPERATING: -40F to +158F (-40C to +70C)

The iKey SLK-102-461-FSR Military Grade Backlit Rugged Keyboard is designed and engineered for use in demanding environments where reliability, durability are essential. The SLK-102-461-FSR supports a wide range of industries and operational applications.

Common deployment industries include: Construction, Defence And Military, Emergency Services, Energy and Utilities, Industrial Manufacturing, Marine And Offshore, Oil and Gas, Rail And Transport.

Across these sectors, the SLK-102-461-FSR is typically used in applications such as Emergency Dispatch And Incident Management, Field Data Capture And Reporting, Health, Safety, And Compliance Inspections, Industrial HMI And Machine Interfacing, Preventive And Corrective Maintenance, Robotics And Autonomous System Control, SCADA And Control-Room Access, Secure Communications And Command-And-Control.

These examples demonstrate the versatility of the SLK-102-461-FSR across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.

For further information, or to assess whether the SLK-102-461-FSR is appropriate for your specific application, please contact us.

The iKey SLK-102-461-FSR Military Grade Backlit Rugged Keyboard comes with a 3 Years Manufacturers Limited Warranty + Option To Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey SLK-102-461-FSR Military Grade Backlit Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey SLK-102-461-FSR Military Grade Backlit Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey SLK-102-461-FSR Military Grade Backlit Rugged Keyboard or require a custom solution or demonstration?

At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the iKey SLK-102-461-FSR or need a custom solution designed specifically for you, our team of technical experts are ready to assist you.
