Winmate W22IAD7T-OFA3 21.5 Inch Open Frame Panel PC
Designed for industrial environments, the Winmate W22IAD7T-OFA3 21.5 Inch Open Frame Panel PC offers a robust and flexible platform built around Intel Alder Lake processors and reinforced metal housing. Its open frame design allows easy integration into control panels and kiosks, facilitating installation within automation and monitoring systems. The display features a 1920×1080 resolution with 250 nits brightness and a 3000:1 contrast ratio, suitable for clear visuals in sealed and continuous-duty settings.
Engineered to perform reliably between 0°C and 50°C with humidity tolerance up to 90% RH non-condensing, this panel PC supports extended operations in temperature-controlled industrial spaces. Dual Intel Ethernet ports provide stable network connections while TPM 2.0 enhances system security. Multiple USB 3.2 Gen2 Type-A ports, HDMI and DisplayPort outputs deliver flexible connectivity options. A fan-cooled system ensures thermal management, making it appropriate for sustained use in dust-sealed, vibration tolerant operations common in industrial deployments.
W22IAD7T-OFA3 Features
- 21.5” 1920 x 1080 Resolution Open Frame PC
- 12th Gen Intel® Core™ Alder Lake S i9 / i7/ i5 / i3 processor
- 2 x SODIMM, DDR5 4800MHz, support up to 64GB (Max. 32GB for each slot)
- Integrated Dual 2.5 Gigabit Ethernet
- Multi display supports DP 1.4a / HDMI 2.0b (Optional)
- Multiple I/Os, 4 x USB 3.2 Gen2x1, 2 x Serial Ports
- 12 V DC Power input
Request a Quote
Product Type
Manufacturer
Ruggedness
Mounting Format
Screen Size
Country Of Manufacture
Taiwan
Size
21.5 inches
Touch / Glass
Resistive Touch Screen (Optional) Protection Glass Without Touch Function (Optional)
Resolution
1920x1080
Panel Brightness
250.0 nits
Contrast Ratio
3000:1
View Angles
89-89-89-89
Active Area
476.64x268.11 mm
Processor
Intel® Core™ i5-12500TE(up to 4.3GHz) Intel® Core™ i9-12900TE(up to 4.80GHz) (Optional) Intel® Core™ i7-12700TE(up to 4.6GHz) (Optional) Intel® Core™ i3-12100TE(up to 4.00GHz) (Optional)
Chipset
Intel® R680E
Memory
2 x SO-DIMM- DDR5 4800 MHz- 8GB 16GB (Optional) 32GB (Optional) 64GB (Optional)
Storage
1 x M.2 2280 M-Key NVMe SSD 256GB 512GB (Optional) 1TB (Optional) 2TB (Optional) 2 x SATA III for 2.5" SSD/HDD (Only R680E/Q670E version support)(RAID support) (Optional)
Ethernet controller
2 x Intel® Ethernet Controller
Security
TPM 2.0
Operating System
Windows 11 IoT Enterprise (64 bit) (Optional) Windows 11 Pro 64 bit (Optional) Linux Ubuntu 22.04(Do not support Wake on Touch) (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
Dimension
504 x 318 x 83 mm
Weight
5.5 kg
Mounting
Open frame Panel mount (Optional) VESA mount (Optional)
Enclosure
Metal Housing
Cooling System
Fan Design
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
Certification
CE- FCC
USB Port
4 x USB 3.2 Gen2x1 (10Gbps- TypeA) (R680E/Q670E version) 4 x USB 3.2 Gen1x1 (5Gbps- TypeA) (H610E version)
Serial Port
1 x RS232/422/485 (Default RS232) 1 x RS232
LAN
2 x 2.5 Giga LAN RJ45 Connector
Video
1 x DP1.4a DP++ - Max resolution up to 4096x2160@60Hz 1 x HDMI 2.0b - Max resolution up to 4096x2160@60Hz (Optional)
Audio
Mic in Line out
Expansion Port
1 x M.2 2280 M-Key Slot (for NVME SSD) 1 x M.2 2230 E-Key Slot (for Wi-Fi module)
Power Input
1 x 12V DC- Din4 pin connector
Button
1 x Power Button 1 x Reset Button
Accessory
100~240V AC to DC Adapter Power Cord VESA screws
Power Rating
12V DC
Adapter
12V 220W"
The Winmate W22IAD7T-OFA3 21.5 Inch Open Frame Panel PC is designed and engineered for use in demanding environments where reliability, durability are essential. The W22IAD7T-OFA3 supports a wide range of industries and operational applications.
Common deployment industries include: Energy and Utilities, Food And Beverage Processing, Industrial Manufacturing, Logistics And Supply Chain, Pharmaceutical, Public Sector, Retail, Security And Surveillance.
Across these sectors, the W22IAD7T-OFA3 is typically used in applications such as Construction Site Supervision And Reporting, Environmental Monitoring And Data Logging, Industrial HMI And Machine Interfacing, Preventive And Corrective Maintenance, Process Control And Shop-Floor Monitoring, Quality Control And Inspection, SCADA And Control-Room Access, Utilities Inspection And Meter Reading.
These examples demonstrate the versatility of the W22IAD7T-OFA3 across both industry sectors and real-world operational use cases. Its suitability extends well beyond the scenarios listed above, making it a flexible solution for a broad range of requirements.
For further information, or to assess whether the W22IAD7T-OFA3 is appropriate for your specific application, please contact us.
The Winmate W22IAD7T-OFA3 21.5 Inch Open Frame Panel PC comes with a 1 Year RTB UK Warranty With Option To Extend Upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Winmate W22IAD7T-OFA3 21.5 Inch Open Frame Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the Winmate W22IAD7T-OFA3 21.5 Inch Open Frame Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Winmate W22IAD7T-OFA3 21.5 Inch Open Frame Panel PC, or would you like to discuss a customised solution or demonstration?
At RUGGED, we recognise that every project has its own unique demands. If you have any questions about the Winmate W22IAD7T-OFA3 or need a custom Rugged Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
